Multi-Refrigerant Vacuum Charging Machine R134a R410A R32 R290 R404A 5kg Electronic Scale

Brand Name:	HongCe
Model Number:	HC-MVC5000
MOQ:	1 Set
Price:	Negotiation
Payment Terms:	T/T,L/C
Supply Ability:	3 Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangzhou, Guangdong, China

Certification:

Third-party certification certificate(cost additional)

Charging Range:

10 - 5000 G

Charging Accuracy:

±0.5% Of Set Value

Power Supply:

220 V 50/60 Hz

Ultimate Vacuum:

30 Microns

Scale Resolution:

0.5 G

Scale Capacity:

5 Kg

Vacuum Pump:

5 CFM Two Stage

Net Weight:

48 Kg

Packaging Details:

Plywood export case with shock absorbing foam, hose set and English manual included

Highlight:

Multi Refrigerant Vacuum Charging

5kg Electronic Weighing Scale

Five Refrigerant Compatibility

Product Description

Multi-Refrigerant Vacuum Charging Machine with 5 kg Electronic Scale

Service teams rarely work with a single refrigerant any more. This machine stores separate charging parameters for R134a, R410A, R32, R290 and R404A, so switching between jobs only requires selecting the refrigerant on screen instead of changing machines. The 5 kg electronic scale covers small split systems as well as larger commercial circuits.

Key Features

Five refrigerant presets with individual pressure and charge limits
5 kg electronic weighing platform with 0.5 g resolution
Integrated vacuum pump and vacuum hold test before charging
Automatic refrigerant identification warning to prevent wrong selection
Real-time digital pressure, weight and vacuum indication
Compact trolley design with hose storage and tool tray

Technical Specifications

Parameter	Specification
Charging range	10 – 5000 g
Scale capacity	5 kg
Scale resolution	0.5 g
Refrigerant types	R134a / R410A / R32 / R290 / R404A
Vacuum pump	5 CFM two stage
Ultimate vacuum	30 microns
Display	LCD with pressure, weight and vacuum pages
Charging accuracy	±0.5% of set value
Power supply	220 V 50/60 Hz
Net weight	48 kg

Typical Applications

Air conditioning and refrigeration service companies
Heat pump installation and commissioning teams
Cold storage maintenance contractors
Refrigerant cylinder transfer and topping up

Detail Shots

Ordering and Support

The machine ships in a wooden case with vacuum-rated hoses, a 5 kg calibration weight and bilingual operating instructions.

For drawings, refrigerant compatibility confirmation or a quotation, contact our sales engineers with your required charging range and production capacity.
