UL1310 Dielectric Strength Test Instrument With 50g And 100g Metal Pin

Brand Name:	HongCe
Model Number:	HX9801
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 sets /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Product Name:

Dielectric Strength Test Instrument

Dimension:

255mm*120mm*200mm

Standard:

IEC 60065-1, IEC 60950, UL1310

Station:

Metal Bars:

Mass Of Metal Bars:

100g And 50g

Diameter Of Metal Bars:

5mm, 6.8mm

Test Sample:

Insulating Material

Packaging Details:

Carton box

Highlight:

UL1310 Dielectric Strength Test Instrument

100g Metal Pin Strength Test Instrument

5mm Diameter Dielectric Strength Test Instrument

Product Description

UL1310 Dielectric Strength Test Instrument With 50g And 100g Metal Pin

UL 1310 clause 40.2

The insulating material is to be placed between two opposing electrodes . The electrodes are to be cylindrical brass or stainless steel rods 1 / 4 inch ( 6.4 mm ) in diameter , with edges rounded to a 1/32-inch ( 0.8 mm ) radius . The upper moveable electrode is to weigh 50 ± 2 grams to exert sufficient pressure on the specimen to provide good electrical contact . The test potential is to be increased to the test value and the maximum test potential is to be maintained for 1 second . The result is acceptable if there is no dielectric breakdown.

Standard:Confirm to IEC60950 Safety of information technology equipment, IEC60065-1 Audio, video and similar electronic apparatus-Safety requirements, UL1310 Class 2 Power Units clause 40.2.

Application:It is used to test the dielectric strength of the insulating material.

Test sample:Insulating material.

Parameters:

The clamp is applicable of two kinds: Ф5-100 andФ6.8-50. For different testing samples, different metal bar and testing bar are adopted. This testing apparatus is equipped with two kinds of metal bar. They are separately 100g and 50g.

Test object	Insulating materials of audio video apparatus
Reference standard	IEC 60065-1, IEC 60950-1, UL1310
Test	dielectric strength test
Station	1
Metal bars	2 pcs
Mass of metal bars	100g and 50g
Size of metal bars	Ф5-100 and Ф6.8-50
Dimension	255mm120mm200mm

UL1310 Dielectric Strength Test Instrument With 50g And 100g Metal Pin 0

UL1310 Dielectric Strength Test Instrument With 50g And 100g Metal Pin 1
