IEC 60065 2014 Clause 9.1.1.3 Children Test Probe 18 To Test Whether Hazardous Parts Can Be Touched

IEC 60065 2014 Clause 9.1.1.3 Children Test Probe 18 To Test Whether Hazardous Parts Can Be Touched

IEC 60065 2014 Clause 9.1.1.3 Children Test Probe 18 To Test Whether Hazardous Parts Can Be Touched

Brand Name:	HongCe
Model Number:	HT-I12
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T, L/C
Supply Ability:	10 sets per momth

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Hemispherica:

R4.3±0.05

Finger Probe Diameter:

Ф8.6±0.1

Finger Probe Length:

57.9±0.15

Joint Distance:

19.3

Axes Of Joints Diameter:

Ф38.4±0.3

Axes Of Joints Length:

101.6±0.3

Packaging Details:

Aluminum box

Highlight:

audio measurement equipment

,

drop test equipment

Product Description

IEC 60065:2014 clause 9.1.1.3 Children Test Probe 18

Standard:

Conforms to IEC 60065:2014 clause 9.1.1.3, IEC61032 figure 12 finger probe 18, IEC335.1,UL1017.

Application:

It is used to simulate the children who are older than 36 months and younger than 14 years to test whether the hazardous parts can be touched.

Test sample:

Easily accessible enclosure live parts or mechanical parts.

Feature:

Can be combined with the push-pull gauge to achieve force of 10N load test.

Parameters:

Name/Model	Children Finger Probe 18 /HT-I12
Hemispherical	R4.3±0.05
Finger probe diameter	Ф8.6±0.1
Finger probe length	57.9±0.15
Joint distance	19.3
Axes of joints diameter	Ф38.4±0.3
Axes of joints length	101.6±0.3
Handle diameter	Ф38.1±0.3
Handle length	451.6±0.8

Picture for referrence:
