IEC 60529 IPX9K High Temperature High Pressure Water Spray Test Chamber 80℃

Brand Name:	HongCe
Model Number:	HH0807
MOQ:	1 Set
Price:	Negotiation
Payment Terms:	T/T,L/C
Supply Ability:	5 Sets per 3 Months

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

Third-party certification certificate(cost additional)

Test Class:

IPX9 / IPX9K

Water Temperature:

Up To Approx. 80C

Spray Pressure:

High Pressure, Adjustable

Nozzle Positioning:

Programmable Angles And Distance

Control System:

PLC + Touch Screen

Construction:

Stainless Steel Wet Area

Sample Fixture:

Customisable, Turntable Optional

Power Supply:

AC 220V / 380V 50Hz

Compliant Standard:

IEC 60529 (IPX9K), ISO 20653

Packaging Details:

Export-grade plywood case with moisture barrier, sea-worthy packing

Highlight:

IPX9K High Pressure Spray Chamber

High Temperature Water Jet Tester

80C Steam Jet Test Equipment

Product Description

For Products That Face Steam, Heat and Pressure Wash in Real Life

Standard rain and jet tests cover a lot of ground, but they do not reproduce the combined heat, pressure and steam found in vehicle underbody washing, industrial cleaning lines and demanding outdoor installations. This IPX9K high temperature high pressure water spray test chamber addresses that gap. It is engineered for the high-pressure, high-temperature jet requirements associated with the IPX9 / IPX9K rating, so manufacturers can validate seals against conditions closer to real-world service.

Built by a team that has supplied enclosure test equipment to automotive and industrial customers, the chamber focuses on the details that matter: stable water temperature, repeatable nozzle position, accurate pressure and controlled test cycles.

Core Capabilities

Hot high-pressure jet: water delivered at elevated temperature for IPX9K class testing.
Repeatable nozzle positioning: programmable angles and distances keep results consistent between runs.
Temperature and pressure control: monitored parameters ensure the test conditions stay within spec.
Sturdy wet-area construction: stainless steel surfaces handle continuous hot water exposure.
Safety interlocks: protection against high-temperature and high-pressure hazards during operation.

Applications

Typical users include automotive and motorcycle component suppliers, EV charger and charging pile manufacturers, industrial enclosure builders and producers of outdoor electrical equipment. Where a product must demonstrate resistance to close-range, high-temperature water spray, this chamber provides the evidence.

Technical Highlights

Test class: IPX9 / IPX9K high temperature high pressure spray
Water temperature up to approximately 80C
High pressure spray with adjustable stand-off distance
PLC control with programmable spray sequences
Stainless steel interior and drainage system
Configurable sample fixtures and turntable options

Working With Our Engineers

Because IPX9K testing is often part of a broader certification programme, we help customers plan how this chamber fits alongside their existing rain and immersion equipment. Provide your target rating and sample type, and we will prepare a free test proposal with recommended parameters and fixtures.

Frequently Asked Questions

Is it suitable for automotive parts? Yes, it is commonly used to validate automotive and motorcycle components against high-pressure hot spray.

Can parameters be customised? Temperature, pressure, cycle and nozzle configuration can be tailored to your standard and sample.

Does it integrate with other test steps? It can be planned as part of a wider waterproofing setup, typically following or preceding IPX5/IPX6 testing.

Need to add IPX9K capability to your lab? Contact us with your requirements and we will outline the right configuration.
