IEC 60529 IP5X IP6X Sand Dust Test Chamber 1000L Vacuum PLC Control System

Dust protection is often the rating that separates a product which survives a dusty jobsite from one that fails in the field. This IP5X/IP6X sand and dust test chamber was designed around the practical reality of testing large enclosures — from automotive control units to outdoor luminaires — while keeping the dust distribution uniform and repeatable. It is built to IEC 60529 clause 13 procedures, with the dust specification and vacuum conditions implemented as the standard requires.

The chamber uses a dedicated circulation and vacuum system so the sample interior is subjected to the correct differential pressure during the test. A PLC and touch screen interface lets technicians configure test duration, vacuum level and cycle profiles, and the sealed cabinet keeps the working environment clean while protecting staff.

• Standard-compliant dust: talc-based test dust prepared to pass the required 50um / 75um sieve specification.
• Uniform dust distribution: internal circulation keeps particle concentration stable throughout the run.
• Programmable vacuum: controlled extraction mirrors real pressure differences across the enclosure.
• Large sample capacity: generous internal dimensions accommodate bulky products and fixtures.
• Operator comfort: sealed enclosure and dust recovery reduce exposure and cleanup time.

Customers apply this dust chamber in automotive electronics validation, outdoor lighting certification, industrial enclosure manufacturing, renewable energy component testing and appliance development. It is a natural companion to a waterproof test system when a product must claim a complete IP rating such as IP65 or IP66.

• Internal working volume: 1000L
• Dust concentration and circulation per IEC 60529 clause 13
• PLC + touch screen control with programmable test cycles
• Integrated vacuum and pressure monitoring system
• Powder recovery and filtration to keep the lab clean
• Interior lighting and sample power feed for live testing

Because dust chamber sizing depends heavily on sample dimensions and fixture design, our engineers review your product drawings before quoting. We provide a free test proposal that recommends chamber size, vacuum parameters and loading method so the equipment integrates cleanly into your existing lab.

Does it test both IP5X and IP6X? Yes, the chamber is configured for both dust protection levels and the difference is managed through the test program.

Can it run energised tests? Yes, internal power feed points allow samples to operate during dust exposure where the standard allows.

How is cleanliness maintained? A dust recovery and filtration loop captures particles after the test to simplify maintenance.

Planning an IP5X or IP6X certification project? Send us your enclosure dimensions and we will recommend the right configuration.
