High-Precision Tumble Drop Tester with 500mm Height and 5 r/min Speed for IEC 60068-2-31 Compliant Testing

Brand Name:	HongCe
Model Number:	HC9922
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third part calibration certificate(cost additional)

Product Name:

Rotating Barrel Test Apparatus

Barrel Number:

One Or Two

Speed Of Rotation:

5 R/min

Falling Times:

10 Times/min

Height Of The Falls:

500mm

Application:

Appliance Mechanical Strength Test

Standard:

IEC 60335-1, IEC 60068-2-31

Test Time:

100 Or 50 Times

Packaging Details:

Plywood

Highlight:

IEC 60068-2-31 Compliant Tumble Drop Tester

500mm Height Drop Tester

5 r/min Speed Rotating Barrel Test Apparatus

Product Description

High-Precision Tumble Drop Tester | IEC 60068-2-31 Compliant Equipment for Smart Home Appliance Durability Tests

Ever wonder what your appliances go through before they get to your home? Think of the roller drop tester as a quality bodyguard. We know every appliance represents a company's commitment to quality and families' hope for lasting products. By recreating actual drops, we spot potential issues early. This way, everything arrives in tip-top shape.

Product Features

High-precision roller design: Simulates multi-angle drop paths, realistically recreating the transportation environment.
Adjustable drop height: Meets the testing needs of various household appliances in terms of size and weight.
Intelligent control system: Equipped with digital display and automatic counting function, easy to operate.
Rugged and durable structure: Constructed with high-strength steel and a shock-resistant base, extending the equipment's lifespan.
Safety protection design: The testing chamber is equipped with a transparent protective cover to ensure operator safety.

Compliance Standards

IEC 60335-1: 2020 Household and similar electrical appliances – Safety – Part 1: General requirements clause 21.1
IEC 60068-2-31: 2008 Environmental testing – Part 2-31: Tests – Test Ec: Rough handling shocks, primarily for equipment-type specimens clause 5.3 and Annex A

Technical Specifications

Model	HC9922
Power Supply	220V, 50Hz
Speed of rotation	5 r/min
Falling times	10 times/min
Counter	0~9999
Material	The body of the rotating barrel is of sheet of 1.5 mm thickness. The smooth, rigid, steel test surface at each end, 3 mm in thickness, is backed by wood of between 10 mm and 19 mm thickness.
Height	500 mm

Product Applications

The drop tester is primarily used to test the impact resistance of household appliances, consumer electronics, lighting equipment, and small appliances under different drop angles.

Typical Applications Include

Rice cookers, electric kettles, vacuum cleaners
Air conditioner remote controls, TV remote controls
Electric shavers, hair dryers
Portable speakers, home control panels
Smart home devices and modules

Testable Items Include

Drop strength and impact resistance
Shell structure durability testing
Internal component loosening detection
Packaging drop and shock resistance performance evaluation
Product comprehensive transportation reliability verification

Product Images
