| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HJ0613A |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 set per month |
| Product Name: | Kettle Withdrawn Testing Equipment | Test Station: | One Station |
|---|---|---|---|
| Withdrawn Speed: | 0-30 Times/min, Adjustable | Withdrawn Stroke: | 0-100mm |
| Output Current: | 0-15A | Drive Method: | Motor-driven |
| Application: | Kettle Life Test | Test Time: | 10 000 Times |
| High Light: | Single Station Home Appliance Testing Equipment,15A Home Appliance Testing Equipment |
||
Home Appliance Testing Equipment Kettle Withdrawn Test With 15A Output Current
Standard of Home Appliance Testing Equipment:
IEC 60335-2-15 Household and similar electrical appliances – Safety – Part 2-15: Particular requirements for appliances for heating liquids clause 22.103;
IEC 60335-2-14 Household and similar electrical appliances – Safety – Part 2-14: Particular requirements for kitchen machines clause 22.103;
IEC 60335-2-3 Household and similar electrical appliances – Safety – Part 2-3: Particular requirements for electric irons clause 22.105;
Feature of Home Appliance Testing Equipment:
The appliance coupler of cordless kettles shall be constructed to withstand the stresses occurring during normal use.
The two live pins of the kettle are connected together and an external resistive load is connected in series with the supply. The external load is such that the current is 1,1 times rated current.
The kettle is placed on its stand and withdrawn 10 000 times at a rate of approximately 10 times per minute. The test is continued for a further 10 000 times without current flowing.
The test is carried out without current flowing if the connection contacts cannot make or break on load.
Parameter of Kettle Withdrawn Testing Equipment:
| Parameters / Model | HJ0613A |
| Input Power | AC220V 50HZ |
| Control | PLC control, touch screen operation |
| Station | Single station |
| Drive Method | motor-driven |
| Test Sample | Cordless kettles, cordless blenders, cordless irons |
| Withdrawn Stroke | 0-100mm,can be preset on touch screen |
| Withdrawn Speed | 0-30 times/min, can be preset on touch screen |
| Test Cycles | 0-999999,can be preset on touch screen |
| Conduction Cycles | 0-999999, can be displayed |
| Mechanical action | Withdrawn action and kettle switch open and close movement |
| Load | Built-in 0-250V,0-15A |
| Sample judgment | Judge conduction according to the current |
