Home Appliance Cord Anchorage Pull Force And Torque Testing Equipment

Brand Name:	HongCe
Model Number:	HJ0609
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third part calibration certificate(cost additional)

Product Name:

Cord Anchorage Pull Force And Torque Testing Equipment

Test Station:

One Station

Torque Load:

5N, 12.5N, 17.5N, One Of Each

Pull Force Load:

10N, 20N, 30N, Two Of Each

Pull Test Time:

25 Times

Torque Test Time:

1 Min

Torque:

0.1Nm,0.25Nm,0.35Nm

Drive Mode:

Stepper Motor Drive

Packaging Details:

Plywood

Highlight:

Pull Force And Torque Testing Equipment

Home Appliance Cord Torque Testing Equipment

Product Description

Home Appliance Cord Anchorage Pull Force And Torque Testing Equipment

Standard of Home Appliance Testing Equipment:

IEC 60335-1 Household and similar electrical appliances – Safety – Part 1: General requirements clause 25.15;

IEC 60884-1 Plugs and socket-outlets for household and similar purposes – Part 1: General requirements clause 23.2;

Application of Cord Anchorage Torque Testing Equipment:

Appliances provided with a supply cord, and appliances intended to be permanently connected to fixed wiring by a flexible cord, shall have a cord anchorage. The cord anchorage shall relieve conductors from strain, including twisting, at the terminals and protect the insulation of the conductors from abrasion.

Parameter of Home Appliance Testing Equipment:

Power Supply	AC220V, 50HZ
Pull force weights	10N2,20N2,30N*2( the pulling force of 30N,60N,80N,100N can be achieved)
Torque weights	5N12.5N17.5N*1(the torque force 0.1Nm,0.25Nm,0.35Nm can be achieved)
Test times	0~9999(selectable),25 times is by default
Pull force frequency	1 times/s
Torque arm	20mm
Torque time	0.01S～99 hours 99 min
Clamp	Combined clamp for both pull force and torque, matching by the bearing, can reduce the friction when processing torque test

Home Appliance Cord Anchorage Pull Force And Torque Testing Equipment 0
