IEC 60335 Home Appliance Testing Equipment For Power Cord Flexing Test

IEC 60335 Home Appliance Testing Equipment For Power Cord Flexing Test

Brand Name:	HongCe
Model Number:	HJ0608B
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Product Name:

Power Cord Flexing Test Apparatus

Usage:

Power Cord Flexibility Performance Test

Standard:

IEC 60335-1

Flexing Angle:

Left 45˚, 60˚, 90˚; Right 90˚, 120˚,180˚;

Flexing Speed:

0-60 Times/min

Load Voltage:

0-250V

Current Detection:

Judge The Conduction By Current

Load Weight:

5N,10N

Current Range:

0-20A

Control Method:

PLC Control, Touch Screen Operation

Packaging Details:

Plywood

Highlight:

IEC 60335 Home Appliance Testing Equipment

Power Cord Home Appliance Testing Equipment

Product Description

IEC 60335 Home Appliance Testing Equipment for Power Cord Flexing Test

Description of Home Appliance Testing Equipment:

Power Cord Flexing Test equipment is professional in testing and Measuring the quality of the power cords. It has been using in many large and famous laboratory such as SGS, BV, Intertek Testing Service, UL International etc. There are total three or six testing groups for the user who can test three or six samples in same time. The machine will be stop operation automatically and the pass lamp will be light when finished all the test requirement. Test cycle will be show on the counter for reference. Remember to reset the counter to zero before you start to test another power cord.

Standard of Home Appliance Testing Equipment:

IEC 60335-1 Household and similar electrical appliances – Safety – Part 1: General requirements Clause 23.3 and 25.14.

Parameter of Home Appliance Testing Equipment:

Item Name	Parameters
Input Power	220V,50Hz
Control Method	PLC control, touch screen operation
Drive	Servo motor
Work station	3/6, synchronous control
Flexing angle	Left 45˚, 60˚, 90˚; right 90˚, 120˚,180˚; The horizontal position or vertical position of the center point are optional; Each station has a dial for corresponding reference
Flexing speed rate	Auto flexing speed 10~60 times/min, Manually flexing speed 0-360˚ /S , can be preset
Test times	0~999999 times, can be preset and displayed
Load weights	5N3,10N3
Specimen fixture	3 sets of universal fixtures, the bending point can be up, down, left, right regulated.
Action principle	Adopts to servo motor drive system, the accuracy of the swing angle and speed regulation are high
Conduction detection	The test device is equipped with power supply sockets for the test samples, and it has a conduction detection function, if there is no current go through the test sample, the indicator light turns on, alarm occurs and the test stops, the corresponding work station records the real-time test times

IEC 60335 Home Appliance Testing Equipment For Power Cord Flexing Test 0
