380V / 50Hz Helium Leak Testing Equipment With 8 Station PLC Control

Name: 380V / 50Hz Helium Leak Testing Equipment With 8 Station PLC Control
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: PH-1
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	PH-1
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	1 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Quality delivery report

Model:

PH-1

Detection Speed:

500 Piece/h

Power Supply:

380V / 50Hz

Helium Injection Pressure:

2.5bar

Station:

Alarm Leakage Rate:

1*10-8 Pa▪m3/S

Packaging Details:

Plywood

Highlight:

8 Station Helium Leak Testing Equipment

PLC Helium Leak Testing Equipment

Product Description

380V/50Hz Helium Leak Testing Equipment With 8-station PLC Control

Product presentation:

According to the basic leak detection principle of helium leak detection, helium is used as a tracer gas, helium is filled in the vacuum box, and then evacuated through the workpiece, and the helium leak detector can judge the leak situation of the workpiece quickly and accurately with high precision.

Basic function of the Helium Leak Testing Equipment:

The operator will put the empty box, use the fixture to fix and wait for the vacuum box door to close, the system can fully complete the vacuum, helium filling, micro leakage detection function, this equipment has the production time fast, high leak detection accuracy.

Technical parameters of Helium Leak Testing Equipment:

No.	Project	Parameter
1	Job type	Relay ceramic housing
2	Station number	8
3	Modality	STD
4	Helium injection pressure	2.5bar
5	Alarm leakage rate	1*10-8 pa▪m3/S
6	Detection speed	500 pieces/hour
7	Helium recovery system	No recovery, but reserve helium recovery interface
8	Power supply	380V / 50Hz
9	Equipment power	5 KW
10	Size	Length 2000mm x width 2500mm x height 2000mm

Product detail picture:

380V / 50Hz Helium Leak Testing Equipment With 8 Station PLC Control 0
