|Place of Origin:||China|
|Certification:||Calibration Certificate(cost additional)|
|Minimum Order Quantity:||1 set|
|Delivery Time:||30 days|
|Supply Ability:||1 Sets per month|
|Warranty:||12 Months||Workpiece:||Air Conditioner Heat Exchanger|
|Chamber Size:||2m*2.5m*1.3m||Gas For Gross Leak Detection:||Nitrogen|
|Gross Leak Pressure:||0.1-4.5Mpa||Tracer Gas:||Helium|
|Equipment Alarm Leak Rate:||1g/year||Cycle:||20 Minutes/chamber|
0.1Mpa Helium Leak Testing Equipment,
20 Minutes Helium Leak Testing Equipment
20 Minutes/Chamber Helium Leak Testing Equipment 0.1Mpa - 4.5Mpa Gross Leak
Helium Leak Testing Equipment Basic working principle :
According to the basic leak detection principle of helium leak detection, helium gas is used as tracer gas, and helium gas is filled into the workpiece in the vacuum box, and then the leakage of the workpiece can be quickly and accurately judged by the helium leak detector.
Helium Leak Testing Equipment Basic functions :
The operator connects the workpiece interface with the quick connector in the vacuum box. After the door of the vacuum box is closed, the system can automatically complete the large leak detection, vacuuming, helium filling, micro leak detection, helium recovery, and fast production tact. High leak detection accuracy .
Helium Leak Testing Equipment Basic technical indicators :
|Workpiece||Air conditioner heat exchanger|
|Chamber size||2m*2.5m*1.3m (dimensions provided by the user)|
|Number of vacuum chambers||1|
|The pipeline in the vacuum chamber||2 roots Helium Leak Testing Equipment|
|Gas for gross leak detection||Nitrogen|
|Gross Leak Pressure||0.1- 4.5 Mpa ( this range is adjustable )|
|Equipment alarm leak rate||1g/year ( 5 *10- 7pa.m 3 /s )|
|Leak helium pressure||0.1- 4.5 Mpa ( this range is adjustable )|
|Production cycle||20 minutes/chamber (close to open)|
|Customer Process Tube Channel Diameter||Inner diameter ≥ 8mm|
|Workpiece loading and unloading||Manual loading and unloading|
|Data storage||With data storage function|
|Scan code||With scan code gun|
|Quick Clamps/Connectors||1 set|
Helium Leak Testing Equipment Advantage:
Equipped with an all-in-one computer , equipped with a two-dimensional code scanning gun to read the product code (the scanning gun is provided by the equipment supplier), the data of product code, inspection time, inspection personnel, total production, yield rate, defective rate and other data can be real-time Save as ACCESS database , and can export Excel files at the same time, the software has a variety of models corresponding to specifications and parameter memory, and the operation is simple and convenient.
