| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration Certificate(cost additional) |
| Model Number: | HJ0616 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Plywood |
| Delivery Time: | 30 days |
| Payment Terms: | T/T |
| Supply Ability: | 10 Sets per month |
| Usage: | Flexing Resistance Test | Standard: | IEC60335-2-2 |
|---|---|---|---|
| Warranty: | 1 Year | Application: | Current-Carrying Hoses |
| Flexing Angle: | 40°±1°, Can Be Preset | Flexing Speed: | 10r/min (that Is 60°/s) |
| Mass Weight: | 5 Kg | Swing Arm Length: | 300mm±50mm |
| Highlight: | Current Carrying Hoses Flexing Resistance Tester,Touch Screen Hoses Flexing Resistance Tester |
||
Home Appliance Testing Equipment Current-Carrying Hoses Flexing Resistance Test
Standard of Home Appliance Testing Equipment:
IEC60335-2-2 Household and similar electrical appliances – Safety – Part 2-2: Particular requirements for vacuum cleaners and water-suction cleaning appliances clause 21,103 and Figure 102
Purpose of Home Appliance Testing Equipment:
It is used to test whether the Current-carrying hoses is resistant to flexing.
Sample range of Current-Carrying Hoses Flexing Resistance Tester:
vacuum cleaner tube, suction cleaner tube, washing machine water pipe
Structure and function:
The device adopts the bending machine mode, the use of PLC control, touch screen operation, bending Angle, bending rate can be preset, reach the number of automatic stop.
During the test, the pivot arm of the end fixed device of the current carrying hose intended to be connected to the power cleaning head is placed on the pivot arm shaft and the distance between the hose and the point where the hose reaches into the rigid part is 300 soil 50mm. A weight with a mass of 5kg is hung on the other end of the hose (the weight can slide along the weight slide), from the level to 40°±1, and this cycle is 2500 times. Then turn the end of the hose to 900 and repeat the above test 2500 times. After the test is completed, the electrical strength test of the sample is carried out.
Technical Parameters of Home Appliance Testing Equipment:
| NO. | Project | Parameter |
| 1 | Power supply | 220V,50Hz |
| 2 | Control and operation | PLC intelligent electrical control, touch screen operation |
| 3 | Work station | 1 |
| 4 | Bending speed | 10r/min(60°/s) |
| 5 | Bending Angle | 40°±1° |
| 6 | Load weight | 5kg |
| 7 | Size | 1000x500x1100mm |
| 8 | Weight | 100kg |
Standard figure:
Picture for reference:
