Helium Leak Testing Equipment for High Voltage DC Relay for New Energy Vehicles With One Test Chamber

Helium Leak Testing Equipment for High Voltage DC Relay for New Energy Vehicles With One Test Chamber

Brand Name:	Hongce
Model Number:	KF30
MOQ:	1set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	1 set per three month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Product Name:

Helium Leak Testing Equipment

Application:

High Voltage DC Relay For New Energy Vehicles

Test Gas:

Helium (He)

Station Number:

1 Station

Warranty:

12 Months

Material:

Stainless Steel And Alluminum

Working Medium:

Helium /hydrogen Gases

Display:

LCD

Packaging Details:

Plywood

Highlight:

Battery Shell Helium Picking Equipment

Single Box Helium Picking Equipment

Product Description

Helium Leak Testing Equipment for High Voltage DC Relay for New Energy Vehicles With One Test Chamber

Introduction of Helium Leak Testing Equipment:

The Helium Leak Testing Equipment uses touch screen and push-button switch to display and control, manually place the workpiece, and test 1 product each time. Products of different specifications can be tested by replacing the leak detection tool. During the system leak detection, the workpiece to be tested is placed on the leak detection tool manually, and the leak detection tool is connected with the leak detector through the leak detection switch valve. After the workpiece is secured, the cylinder descends to push the helium nozzle to press the workpiece. Then the auxiliary pump is started to vacuum the inside of the workpiece. Then the leak detector continues to pump out to clear the background, and when the leak detector reaches the background value, the equipment sprays helium. The leak detector determines the leak rate according to the helium infiltration.

Feature of Helium Leak Testing Equipment:

1. Helium mass spectrum leak detector: leak detection equipment, including the main engine and mechanical pump two parts

2. Leak detection tooling: Matching fixture customized according to different products, including island valve, gas path, machined parts, etc

3. Electronic control system: one-click operation of the entire leak detection system, automatic completion of the leak detection process, including switch buttons, touch screens, etc

4. Pneumatic actuator: air source processing accessories, valves, cylinders, pipelines, joints, etc

Technical parameters

capacity	≥50pcs/H
Tracer gas	Helium (He)
leak rate	When 1*10-8 Pa·m3/s is reached, helium is sprayed to detect the leak
Helium recovery	Do not recycle
Number of empty containers	1 test chamber (1 product per test)
