3 Vacuum Chambers Helium Leak Detection Equipment For Relay 30s/2PCS

Brand Name:	HongCe
Model Number:	HJ-HS-4
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	20 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Inspected Workpiece:

Relay Products

Number Of Vacuum Chambers:

Large Leak Detection Vacuum:

≤1*10-2 Pa

Detection Of Gases:

Helium

Helium Recovery Or Not:

Production Rhythm:

30s/2PCS

Alarm Leakage Rate:

1.0×10-9 Pa.m3 /sec

Highest Leak Detection Accuracy:

5.0×10-10 Pa.m3 /sec

Packaging Details:

PLYWOOD

Highlight:

30s/2PCS Helium Leak Detection Equipment

Helium Leak Detection Equipment

Vacuum Chambers Helium Leak Testing Equipment

Product Description

3 Vacuum Chambers Helium Leak Detection Equipment For Relay 30s/2PCS

Equipment Overview

Purpose of use: Helium inspection of relay products Helium Leak Testing Equipment

Device Functions and Principles Introduction

The equipment can complete relay scanning, helium leak detection, result determination, data recording and uploading.

Basic technical specifications

Inspected workpiece	Relay Products
Number of vacuum boxes	3 (two leak detection ports for each vacuum chamber, total 6 leak detection ports)
Large leak detection vacuum	≤1*10^-2 pa
Detection of gases	Helium
Helium pressure	First class product 0.5MPa Class II product 0.3 MPa Helium Leak Testing Equipment
Helium recovery or not	No recycling
Production Rhythm	30 seconds / 2 pieces
Alarm leakage rate	1.0×10^-9 Pa.m³ /sec
Highest leak detection accuracy	5.0×10^-10 Pa.m³ /sec Helium Leak Testing Equipment
Equipment stability	The equipment is equipped with a point leak detection hole, and the leak detection data of each hole is in accordance with the European industry standards for equipment: USL and LSL.

Description of the technical characteristics of the equipment

Background cleaning technology

The residual helium signal in the vacuum chamber after the test is called background noise. The background noise may leak into the vacuum chamber from the leak detection system itself or accumulate from the previous test.

Our patented helium background noise cleaning technology can effectively remove the helium background noise of the vacuum chamber system, provide a clean and stable environment for the system, avoid the system's helium background noise level exceeds the standard, which affects the stability of the system operation, and improve the operating efficiency of the system.

3 Vacuum Chambers Helium Leak Detection Equipment For Relay 30s/2PCS 0
