| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HH0804 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | plywood |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20 set per month |
| Test Object: | Enclosures | Standard: | IEC 60529, EN 60529 |
|---|---|---|---|
| Test: | Protection Against Water | The Nozzle Diameter: | Ф6.3mm; Ф12.5mm |
| Distance To Enclosure: | 2.5~3m | Testing Time: | Not Less Than 3min |
| Water Flow: | 12.5L/min; 100L/min | Pressure Gauge: | 0~0.25MPa |
| Highlight: | environmental test chamber,waterproof tester |
||
Handheld Jet Nozzle Tester HH0804
Description:
This is to testing of IPX5 and IPX6 protection aginst water of electronic appliances, lamps, electrical cabinets, electrical components, car, motorcycle, electrical products.
Confirm to standards:
IEC 60529 IPX5, IPX6;
EN 60529 IPX5, IPX6;
IEC 60884-1;
IEC 60598-1;
IEC 60335-1 and so on.
Test Sample: A water-proof test apparatus suitable for diverse electrical items, including electronic appliances, lamps, cabinets, components, vehicles (cars, motorcycles), and specific electrical products like automotive instruments, switches, and micro motors.
Feature: Equipped with a pressure gauge, enabling operation through nozzle replacement. It can integrate with a comprehensive waterproof system.
Technical parameters:
| Model | HH0804-1 | HH0804-2 |
| Item | IPX5 Jet nozzle | IPX6 Jet nozzle |
| The nozzle diameter | Ф6.3mm | Ф12.5mm |
| Water flow | 12.5±0.625L/min, Flow meter is adjustable | 100±5 L/min, Flow meter is adjustable |
| Water supply |
Water flow rate ＞12.5L/min±5% clean water without inclusion. It can be achieved by the stainless steel water tank and pressurized equipment |
Water flow rate ＞100L/min±5% clean water without inclusion. It can be achieved by the stainless steel water tank and pressurized equipment |
| The distance from jet nozzle to enclosure | 2.5~3m | |
| Testing time | 1min/m²(not less than 3 min) | |
| Pressure gauge | 0~0.25MPa | |
| Site requirements |
Dedicated IP waterproof test room whose width is more than 3m, With good function of inflow and drainage. Wall installation |
|
