IEC 60598-2-8 Handlamp Impact Tester 400mm 1000mm Drop Heights

Brand Name:	HongCe
Model Number:	HL-1
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Usage:

Impact Resistance Test

Warranty:

1 Year

Product Name:

Impact Tester For Handlamps

Standard:

IEC60598-2-8

Material:

Stainless Steel And Aluminum

Impact Height:

400mm/1000mm

External Dimensions:

1250mm×1500mm×200mm

Packaging Details:

Plywood case

Highlight:

IEC 60598-2-8 handlamp impact tester

handlamp drop tester 400mm 1000mm

light testing equipment with warranty

Product Description

Professional Handheld Lamp Impact Resistance Tester

IEC 60598-2-8 Compliant testing equipment with 400mm & 1000mm drop heights for portable luminaire safety testing.

Key Specifications

Attribute	Value
Usage	Impact resistance test
Warranty	1 Year
Standard	IEC60598-2-8
Material	Stainless steel and aluminum
Impact height	400mm/1000mm
External dimensions	1250mm×1500mm×200mm

Product Overview

Our handlamp impact tester complies with IEC60598-2-8:2007 standards (section 8.6.6.2 and Figure 1) for evaluating the durability of portable luminaires. This wall-mounted testing device requires secure installation on a solid brick, stone, or concrete surface and is manually operated.

Technical Parameters

Model: HL-1
Bar size: 40mm×40mm×5mm right-angle section with 5mm radius corners
Impact heights: 400mm and 1000mm configurations
Construction: Durable stainless steel and aluminum frame

Testing Procedure

1. Suspend the handlamp (without lamp) by its cord with point A touching the bar's corner (400mm suspension height)

2. Pull the lamp away until the cord is horizontal, then release to impact the bar

3. Repeat three times at point A, then at points B and C

4. Verify the lamp remains safe and functional

5. Repeat entire test at 1000mm suspension height

6. Confirm protective components remain in place (minor bending acceptable)

7. Glass/clear cover breakage is acceptable if not the sole protection
