6-Station Temperature Rise Tester Complies With IEC 60898-1 Standard Test Voltage <12V

Name: 6-Station Temperature Rise Tester Complies With IEC 60898-1 Standard Test Voltage <12V
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HC9910C
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HC9910C
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third party calibration certificate(cost additional)

Standart:

IEC60884-1

Working Station:

Testing Current:

0-125A

Testing Voltage:

＜12V

Temperature Measuring Meter:

0-150℃ Digital Display

Test Object:

Connector

Control Method:

PLC Control

Operate Method:

Touch Screen Operation

Packaging Details:

plywood

Highlight:

IEC 60898-1 Temperature Rise Tester

12V Temperature Rise Tester

6-Station Temperature Rise Tester

Product Description

6-Station Temperature Rise Tester | Complies With IEC 60898-1 | Standard Test Voltage <12V

Product Introduction
In modern industrial production, the quality and performance of connectors are crucial. As a source manufacturer, we are proud to launch the HC9910C temperature rise tester, a high-end device designed specifically for connector testing. This device not only complies with the IEC 60898-1 international standard, but also has high-precision testing capabilities and a user-friendly operating interface, ensuring the accuracy and reliability of the test.

Product Features
• High-precision testing: 0-125A test current and <12V test voltage ensure the accuracy of test results.
• Multi-function operation: touch screen operation and PLC control provide flexible test settings and data management.
• Temperature control: 0-150°C digital display temperature control to meet the needs of different test environments. • High efficiency: 6 workstations design to improve test efficiency and shorten test time.

Product Use
HC9910C temperature rise tester is widely used in connector manufacturers, electronic product testing laboratories and quality control departments. It can detect the temperature rise of connectors under different current and voltage conditions to ensure the safety and stability of products in actual use.

International Reference Standards
IEC 60898-1: General requirements and test methods for connectors.

Test objects and items
HC9910C temperature rise tester is suitable for various types of connectors, including but not limited to:
• Automotive connectors
• Industrial connectors
• Consumer electronics connectors
It can detect the following items:
• Temperature rise test
• Current load test
• Voltage stability test

Parameters:

Item	HC9910C
Working station	6
Testing current	0-125A
Testing voltage	＜12V
Timer	0-9999s is adjustable, digital display
Temperature measuring meter	0-150℃ digital display
Power supply	220V,50HZ
standard	IEC 60998-1
Test object	connector

Picture for reference:

6-Station Temperature Rise Tester Complies With IEC 60898-1 Standard Test Voltage <12V 0

After-sales service:
Worry-free after-sales service, full escort
Warranty: One-year free warranty for the whole machine, lifelong technical support.
Response: 30+ service outlets nationwide, fast on-site inspection and repair.
Operation training: Provide on-site/remote equipment use teaching.
Software upgrade: Synchronous IEC standard update to ensure long-term applicability of the equipment.

Tips: For more product information, please consult our salesperson
