| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | CXT2510 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 45 days |
| Payment Terms: | T/T |
| Supply Ability: | 1 Sets per month |
| Feature Length: | 150cm | Power Supply: | 220V 50Hz |
|---|---|---|---|
| Testing Range: | 200 µΩ~20 KΩ | Measuring Material: | Wire And Cable, Metal, Etc |
| Measuring Error: | ≤0.01% | Guarantee Period: | 1 Year |
High Precision IEC 60228 Conductor Resistance Tester for Ultra Low DC Resistance Testing
The CXT2510 Ultra low DC resistance tester is a high-precision instrument. It features a wide measuring range from 0.01uΩ to 10MΩ with five and a half display bits. It uses automatic bidirectional current and pulse test methods for accurate results, with a test speed up to 30 times/second and the highest accuracy of 0.02%. Temperature compensation is available. It has multiple interface functions like RS232 and USB for data communication and remote control. The professional sorting function is useful in automatic sorting systems. It can be applied to test various ultra-low DC resistance/resistivity in wire and cable, shunt, metal, conductor, switch contact resistance, connector contact resistance, relay wire package and contact resistance, transformer, inductor, motor, deflection coil winding resistance (inductive load in unidirectional current mode), wire resistance, metal riveting resistance for vehicles and aircraft, and printed board lines and perforated resistance.
Technical parameters:
CXT150m fixture
CXT2510 Ultra-low DC resistance tester
The company has its own developing and designing team, ensuring technological and innovative products for customers.
Can provide a unique design according to customers' ideas.
All workers are experienced and skilled.
The working and sales teams can guarantee fast and high-efficiency after-sale service globally.
Guangzhou Hongce Equipment Co., Ltd, established in 2003 in Guangdong, China, is a leading inspection equipment company.
It integrates advanced equipment with modern production processes and a stringent quality control system.
Specializes in producing various inspection equipment like electric wire inspection equipment of plug and socket, mechanical robustness testing equipment of electronics, inspection equipment of electronics’ on-fire danger, testing indicator of anti-electric shock and solid objects' entry, general inspection equipment, and non-standard testing equipment.
Has excellent sales performance domestically and internationally and supply partnerships with many reputable companies.
