Reliable PLC-Controlled Water Resistance Test Device for IP Testing Equipment

Name: Reliable PLC-Controlled Water Resistance Test Device for IP Testing Equipment
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HH0819
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HH0819
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	L/C, T/T
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Standard:

IEC60529

Control Mode:

PLC Control

Turntable:

Diameter 800mm

Drip Box:

1000*600mm

Oscillating Tubes:

R200mm, R400mm, R600mm, R800mm, R1000mm, R1200mm, R1400mm, R1600mm

Warranty Period:

1 Year

Packaging Details:

Plywood

Highlight:

PLC-Controlled Water Resistance Test Device

Reliable Water Resistance Test Device

Product Description

Reliable PLC-Controlled Water Resistance Test Device for IP Testing Equipment

Product Introduction with IP Testing Equipment:

The Water Resistant Test Device consists of the following main parts:

1. Drip box, test area 1000*600mm for IPX1-2 test;

2. R200mm, R400mm, R600mm, R800mm, R1000mm, R1200mm, R1400mm, R1600mm oscillating tubes for IPX3-4 test;

3. Hand-held spray nozzle for IPX3-4 test;

4. Jet nozzle for IPX5-6 test;

5. Diameter 800mm turntable;

6. Water supply tank (also for IPX7 immersion test) and electrical control cabinet;

7. Fixed bracket for hand-held spray nozzle and jet nozzle.

Standard: IEC60529 degree of protection provided by enclosures (IP Code) of the IPX1, IPX2, IPX3, IPX4, IPX5 IPX6, IPX7;

Application with IP Testing Equipment: Water Resistance Testing Evaluated by the Second Characteristic Digit.

Reliable PLC-Controlled Water Resistance Test Device for IP Testing Equipment 0

Reliable PLC-Controlled Water Resistance Test Device for IP Testing Equipment 1

Product Parameters with IP Testing Equipment:

Water Supply	Water flow rate＞10L/min±5% clean water without inclusion. This device is equipped with clean water filtration unit
Oscillating Ttubes Radius	R200, R400, R600, R800, R1000, R1200, R1400, R1600mm are available, made of stainless steel
Needle Hole	Φ0.4mm
Included Angle of Two Holes	IPX3: 120°; IPX4: 180°
Pendulum Angle	IPX3: 120°(±60°); IPX4: 350°(±175°)
Raining Speed	IPX3: 4 s/time(2×120°); IPX4: 12 s/time(2×360°);
Water Flow	Can be set according to the size of the pendulum and the number of the pin holes (0.07 L/min per hole)
Testing Time	0.01s-99hours 59min, can be preset

Dimension	6556101495mm
Observation Window	Toughened Glass Window
Observation Window Dimension	W190mm*H1280mm
Depth Ggauge	Stainless Steel
Liquid Level Control	Float Switch+Overflow Pipe
Control Mode	PLC Control

Drip test area	1000×600mm, customizable
Drip height	200mm, adjustable. Automatically sensed by infrared sensor, when the needle is located at the highest point of the sample 200mm, the drip box will automatically stop.
Dripping rate (Water flow)	1mm/min or 3mm/min switchable, adopt digital controlled rainfall technology
Needle hole	φ0.4mm
Distance between holes	20mm
Testing time	0-999.9min, can be preset
Installation method	Wall mounted or floor type

Our advantage service:

We boast a proficient R&D and design squad that harnesses their expertise and creativity to devise tailored product solutions for our customers. Should you harbor any novel concepts or distinctive product requirements, kindly share them with us. We'll meticulously craft a bespoke design, rooted in your ingenuity and aspirations, ensuring it surpasses all your expectations.

After sale service:

Our dedicated professional team, comprising skilled workers and accomplished sales experts, is steadfast in delivering our products to clients globally while ensuring prompt and reliable after-sales support tailored to meet diverse requirements.

About Us:

Founded in 2003, Guangzhou Hongce Equipment Co., Ltd. is a leading manufacturer specializing in IP Testing Equipment and other inspection solutions in Guangdong, China. Leveraging advanced technologies and a rigorous quality control system, we devote ourselves to the R&D, production, and sales of IP Testing Equipment and a diverse range of inspection tools. Our products, reaching international standards, enjoy strong domestic and international demand, fostering trusted partnerships with numerous renowned companies.
