| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | HJ139 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood |
| Delivery Time: | 90 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 set per month |
| Alarm Leak Rate: | 5E-5 Mbar.l/sec | Energy Consumption: | 15KW |
|---|---|---|---|
| Vacuum Chamber: | 1 Set | Production Speed: | 5min/Piece |
| Minimum Detection Accuracy: | 1.0E-7mbar*L/S | Helium Fill Pressure: | 0-0.5Mpa |
| Dimensions: | ≤2500mm X 2500mm X 2200mm | Weight: | 1000KG |
| Operating Voltage: | 380V | Warranty Period: | 1 Year |
| High Light: | 15KW Helium Leak Detector,0.5Mpa Helium Leak Detector,Automotive Battery Casing Helium Leak Detector |
||
15KW Helium Leak Detector For Automotive Battery Casing For 0-0.5Mpa Battery Testing Equipment
Product Introduction with Battery Testing Equipment:
The automobile battery helium detector is a device used for detecting the helium gas leakage of the new energy vehicle battery cover, which adopts the helium mass spectrometry leak detection technology and has the characteristics of being safe and efficient, easy to operate, accurate and reliable. It can determine whether there are leak points by detecting the internal pressure change of the battery, and has been widely applied in the new energy vehicle production line to increase the detection efficiency and accuracy, and ensure the quality and safety of the vehicle.
Product Features with Battery Testing Equipment:
Automatic Helium Replenishment: Monitors helium concentration and automatically replenishes when insufficient, with adjustable concentration settings.
Helium Concentration Monitoring: Real-time online monitoring and automatic control of injection, ensuring high precision.
Helium Recovery: Integrated recovery system for convenient reuse and increased efficiency.
Access Control: Three-level password protection, granting different levels of access privileges to authorized personnel.
Industrial Computer: Equipped with data processing and storage capabilities, displaying production information and supporting both offline and online operations.
Automatic Calibration: Adjustable calibration intervals, supporting manual calibration with automatic results updating.
Remote Maintenance: Enables remote troubleshooting and problem-solving for seamless device maintenance and support.
Product Parameters with Battery Testing Equipment:
| Alarm Leak Rate | 5E-5 mbar.l/sec |
| Energy Consumption | 15KW |
| Vacuum Chamber | 1 Set |
| Production Speed | 5min/Piece |
| Minimum Detection Accuracy | 1.0E-7mbar*L/S |
| Helium Fill Pressure | 0-0.5Mpa |
| Dimensions | ≤2500mm x 2500mm x 2200mm |
| Weight | 1000KG |
| Operating Voltage | 380V |
Product Image with Battery Testing Equipment:
