IEC 62368 Testing Equipment Steel Ball Impact Test For Enclosure With 50mm Steel Sphere

Brand Name:	HongCe
Model Number:	SH-12
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Steel Ball Diameter:

50mm

Steel Ball Weight:

500±10g

Drop Height:

0.5-1.5m Adjustable

Clamping Release:

Electronic Control

Standard:

IEC 62368-1, IEC 60598-1

Usage:

Drop Impact Test

Test Sample:

Luminaries, Audio

Power:

220V

Packaging Details:

plywood

Highlight:

IEC 62368 Impact Testing Equipment

Steel Ball Impact Testing Equipment

Product Description

IEC 62368 Testing Equipment Steel Ball Impact Test for Enclosure With 50mm Steel Sphere

Standard of Apparatus For Ball Impact Tests:

IEC 62368-1:2023 Audio/video, information and communication technology equipment – Part 1: Safety requirements clause 4.8.4.5 and clause T.6

IEC 60598-1:2020 Luminaires – Part 1: General requirements and tests clause 4.13.4a and figure 21

Application of IEC 62368 Testing Equipment:

The steel ball impact test device is a testing instrument that is mainly used to test the mechanical strength of the equipment shell when it withstands foreseeable operations, especially those equipment whose outer surface is damaged and may touch dangerous parts.

It can perform two types of tests: vertical drop impact and pendulum horizontal impact.

Test sample of Steel Ball Impact Device:

Luminaries, Audio, video and similar electronic apparatus, Information technology equipment

Feature of IEC 62368 Testing Equipment:

Steel ball Diameter: 50mm; Weight: 500g ± 10g.

A variety of steel ball impact optional, can meet different requirements

The steel ball will undergo a free-fall test, impacting the surface of the test specimen, and the extent of damage to the specimen will be observed. The dropping height can be adjusted up and down.

The weight test steel ball can be used for mechanical strength testing of various instrument casings.

Parameters of Apparatus For Ball Impact Tests:

Impact steel ball	Diameter 50mm, 500±10g
Drop height	0.5-1.5m adjustable
Lift mode	Electric
Clamping release mode	Electronic control

IEC 62368 Testing Equipment Steel Ball Impact Test For Enclosure With 50mm Steel Sphere 0

IEC 62368 Testing Equipment Steel Ball Impact Test For Enclosure With 50mm Steel Sphere 1
