IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires

Brand Name:	HongCe
Model Number:	SH-12
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Steel Ball Diameter:

50mm

Steel Ball Weight:

500±10g

Drop Height:

0.5-1.5m Adjustable

Clamping Release:

Electronic Control

Standard:

IEC 62368-1, IEC 60598-1

Usage:

Drop Impact Test

Test Sample:

Luminaries, Audio

Power:

220V

Packaging Details:

plywood

Highlight:

IEC 62368 Impact Testing Equipment

Steel Ball Impact Testing Equipment

Product Description

IEC 62368 Steel Ball Impact Tester 50mm 500g for Luminaires

Product Specifications

Attribute	Value
Steel ball diameter	50mm
Steel ball weight	500±10g
Drop height	0.5-1.5m adjustable
Clamping release	Electronic control
Standard	IEC 62368-1, IEC 60598-1
Usage	Drop impact test
Test sample	Luminaries, Audio
Power	220V

Product Description

IEC 62368 Testing Equipment Steel Ball Impact Test for Enclosure With 50mm Steel Sphere

Compliance Standards

IEC 62368-1:2023 Audio/video, information and communication technology equipment - Part 1: Safety requirements clause 4.8.4.5 and clause T.6
IEC 60598-1:2020 Luminaires - Part 1: General requirements and tests clause 4.13.4a and figure 21

Application

The steel ball impact test device is a testing instrument that is mainly used to test the mechanical strength of the equipment shell when it withstands foreseeable operations, especially those equipment whose outer surface is damaged and may touch dangerous parts. It can perform two types of tests: vertical drop impact and pendulum horizontal impact.

Test Samples

Luminaries, Audio, video and similar electronic apparatus, Information technology equipment

Key Features
