20mm stroke IEC 60730 Test Equipment For Testing Durability Of Markings On Rating Labels

20mm stroke IEC 60730 Test Equipment For Testing Durability Of Markings On Rating Labels

Brand Name:	HongCe
Model Number:	IN-2
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	1 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Product Name:

Apparatus For Testing Durability Of Markings On Rating Labels

Test Stroke:

20mm

Hard White Buffing Felt:

65 X 7.5mm

Brass Washers:

60 X 2.5mm

Mild Steel Strip:

15 X 5mm

Weight:

500g

Packaging Details:

Plywood

Highlight:

IEC 60730 Test Equipment

20mm Stroke IEC 60730 Test Equipment

20mm Stroke IEC Test Equipment

Product Description

IEC 60730 Test Equipment Apparatus For Testing Durability Of Markings On Rating Labels

Standard of Apparatus For Testing Durability Of Markings On Rating Labels:

IEC 60730-1:2015 Automatic electrical controls – Part 1: General requirements clause 7.4 and Annex A, Figure 8

Application of IEC 60730 Test Equipment:

This Apparatus For Testing Durability Of Markings On Rating Labels is used to test the Indelibility of markings.

The principal part consists of a disc of hard white buffing felt, 65 mm in diameter and 7,5 mm thick. This is locked against rotation and is arranged to move across the surface to be tested with a stroke of 20 mm and to exert a measurable force on this surface. The standard test shall be 12 strokes (i.e., rotations of the eccentric) and shall take approximately 15 s.

Technical Parameters for IEC Test Equipment:

Parameter	Specification
Power Supply	AC 220V, 50Hz
Test station	1 station
Test stroke	20mm
Speed	48rpm
Test times	0~99999 preset,default 12 times
Counterweight	500G,without weight 250g,with weight 750g
Brass washers	60*2.5mm
Hard white buffing felt	65*7.5mm
Model	IN-2
