IEC Testing Equipment Programmable Temperature And Humidity Chamber Climatic Test

Brand Name:	HongCe
Model Number:	HH0811
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 sets for month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Product Name:

Programmable Temperature And Humidity Chamber

Heating Rate:

3.0℃/min

Cooling Rate:

1.0℃/min

Refrigerating Method:

Forced Air Cooling

Internal Box Size:

1000×1000×1000

External Box Size:

1200×2035×2050

Equipment Material:

Corrosion Resistant Plate

Power:

380V/60Hz

Packaging Details:

Plywood

Highlight:

Programmable Temperature IEC Testing Equipment

Humidity Chamber IEC Testing Equipment

Product Description

IEC Testing Equipment Programmable Temperature And Humidity Chamber Climatic Test

Product introduction for IEC Testing Equipment:

This testing machine is mainly used for the adaptability test of electronic, electrical, food, automobile, rubber, plastic, metal and other products, parts and materials in high and low temperature alternating wet and hot environment storage, transportation and use.

Purpose for IEC Testing Equipment:

It is suitable for all kinds of electronic, electrical, electrical, plastic and other raw materials and devices to carry out cold resistance, heat resistance, wet resistance, dry resistance test and quality control engineering reliability test equipment;

Product feature for Temperature And Humidity Chamber:

1. Especially suitable for fiber, LCD, crystal, inductance, PCB, battery, computer, mobile phone, rubber, plastic and other products of high temperature resistance, low temperature resistance, moisture resistance cycle test;

2. The machine can simulate different environmental conditions such as high temperature and high humidity/high temperature and low humidity/low temperature and high humidity/high temperature and low temperature, with high accuracy programming control and fixed-point control system that is easy to operate and learn, to provide the best test environment.

Technical parameters for IEC Testing Equipment:

No.	Project	Parameter
1	Temperature range	A:-20～+150℃ B:-40～+150℃ C:-70～+150℃
2	Humidity range	20%～98%RH
3	Temperature departure	±2℃
4	Temperature uniformity	±2℃
5	Temperature fluctuation	±0.5℃
6	Heating rate	Approx. 3℃/min (nonlinear, no-load)
7	Cooling Rate	Average 1.0℃/min (nonlinear, no-load)
8	Humidity deviation	±3.0％RH(＞75％RH)；±5.0％RH(≤75％RH)
9	Humidity uniformity	± 3.0% RH (no load)
10	Humidity fluctuation	±2.5％RH(no load)
11	Inner box material	SUS304 stainless steel plate
12	Power supply	220V±10%V/ 380V±10%V；50Hz；

Product detail picture:

IEC Testing Equipment Programmable Temperature And Humidity Chamber Climatic Test 0
