IEC60529 IP Testing Equipment Sand And Dust Test Chamber For IP5X IP6X

Brand Name:	HongCe
Model Number:	HH0810
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate (Cost Additional)

Rank:

IP5X IP6X

Product Name:

IP5X IP6X Dust Chamber

Dust Temperature Range:

RT+10℃～60℃

Test Sand (or Talc) Dosage:

2kg/m³

Test Dust:

Dry Talc

Sand And Dust Concentration:

2～4kg/m3

Air Flow Speed:

≤2m/s

Power:

380V/60Hz

Packaging Details:

plywood

Highlight:

Waterproof Testing Equipment

Sand And Dust IP Testing Equipment

Product Description

IEC60529 IP Testing Equipment Sand And Dust Test Chamber for IP5X IP6X

Product Introduction for IP Testing Equipment:

IP5X IP6X dust test chamber is a kind of test equipment used to simulate sand and dust environment, which can be used to test the performance and durability of products or materials in sand and dust environment. It is generally composed of chassis, fan, filter system, temperature and humidity control system and control system. The dust test chamber is designed and manufactured according to IEC 60529: 2013 Degrees of protection provided by enclosures (IP Code) Figure 2, IEC60598-1-2008 and other standards.

As an important experimental equipment, the sand and dust test chamber not only plays an important role in academic research, but also plays a key role in industrial production and product quality control. Its appearance and application greatly improve people's awareness and understanding of sand and dust environment, and provide strong support for solving the problem of sand and dust pollution.

Function parameters for IP Testing Equipment:

Model	HH0810
Working size(mm)	W1000D1000H1000
Outer size (mm)	L1850W1350H1800
Main technical parameters	Temperature range	Room temperature
	Test dust	dry talc which can go through the sieve of 75μm and the square sieve of wire diameter 50μm.
	Test sand (or talc) dosage	2kg/m³
	Vacuum pump	Ultimate vacuum:2Pa
	Air pressure meter	0~-1.0Mpa
	Sample rack height adjustment range	0~750MM
	Timing range	0~99 hours 59 min
	Timing accuracy	±1min
	Load cycle control	0~99 hours 59 min
	Ash blowing cycle control	1s~9999 min
	Sand and dust concentration	2～4kg/m3
	Air flow speed	≤2m/s

Product detail drawing for IP Testing Equipment:

IEC60529 IP Testing Equipment Sand And Dust Test Chamber For IP5X IP6X 0
