PLC Battery Leak Testing Equipment For Automotive Steel Case Batteries With One Chamber

Brand Name:	HongCe
Model Number:	HJ098
MOQ:	1 SET
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	2 Sets Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Data Storage:

With Data Processing And Parameter Storage Function

Detectable Leak Rate:

1.0x10-9～9.0x10-3Pa・m3/s

Operating Temperature:

0-40℃

Tested Product:

Battery Pack, Battery Tray, Battery Cases

Control:

PLC Control

Loading And Unloading Products:

Manual

Data Analysis:

Real-time, Historical, Statistical

Data Output:

USB, RS232, Ethernet

Packaging Details:

plywood

Highlight:

PLC Battery Leak Testing Equipment

One Chamber Battery Leak Testing Equipment

Product Description

Battery Leak Testing Equipment For Automotive Steel Case Batteries With One Chamber

Application of Battery Leak Testing Equipment:

Leak testing can be performed on the production line using conventional techniques with helium as a tracer gas. Cells can be tested in different stages of the production process: immediately after electrolyte filling and sealing, after formation, or after degassing and subsequent final sealing, and up to the check during the end-of-line testing.

Feature of Battery Leak Testing Equipment:

Depending on the type of cell (button, cylindrical, prismatic or pouch) and its size, special customizations may then be necessary in relation to the dimension and shape of the vacuum chamber, number of cells in the chamber, test time, ...

The picture shows an example of an automatic machine for the leak test for a steel-cased battery, characterized by a rate of 1 cell every 34 second.

In order to prevent contamination of the vacuum chamber, a gross leak test is carried out, in order to discard the batteries with macroscopic defects.

Parameter of Battery Leak Testing Equipment:

Product to be tested	Steel cased batteries after sealing and welding of the filling holes
Alarm leak rate	5E-5 mbar.l/sec
Number of test stations	1 station(customisable)
Helium filling pressure	0-0.5MPa
Large leak detection method	Negative pressure to detect large leakage
Production time	34sec/pc
Product sealing method	Automated
Loading and unloading products	Manual
Fixture	Matching 1 product with 2 sets of fixtures
Data processing	With data processing and parameter storage function

PLC Battery Leak Testing Equipment For Automotive Steel Case Batteries With One Chamber 0
