IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard

IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard

IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard
IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard
IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Third party calibration certificate(cost additional)
Model Number: HDD8304
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: Plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 5 set per month
Contact Now
Detailed Product Description
Control: Mitsubishi PLC Station: One, Can Be Customized
Built-in Load: 0~250V/5KW Test Speed: ≥10 Freq/min
Standard: IEC/EN 60745-2-5 Test Sample: Circular Saws
Warranty: 1 Year Application: Circular Saws Performance Test
High Light:

IEC60745-2-5 Integrated Test Device

,

Circular Saw Switch Integrated Test Device

IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard



Standard of IEC Testing Equipment:

IEC 60745-2-5 Hand-held motor-operated electric tools – Safety – Part 2-5: Particular requirements for circular saws Annex BB.20.102, Annex M21.18, Annex M21.18.301, Annex M21.203, Annex M21.301, figure M.301



Application of IEC Testing Equipment:

It is used to test the circular saw switch performance and circular saw lower guard’s durability and recovery time.





Feature of IEC Testing Equipment:

The saw table shall be provided with a device for locking the switch of the hand-held circular saw in the “on” position. This device shall disengage when the saw is removed from the saw table.

The table shall be provided with a means to keep the lower guard of the circular saw open while mounted to the table. The means proved to keep the lower guard open shall be accomplished by adequate mechanical means.



Parameters of Circular Saw Switch And Lower Guard tester:

Serial No.: Parameter
Input Power 230V/50Hz
Control System PLC + touch screen
Station Single
Built-in Load             0~250V/5KW voltage regulator, equipped with B socket
Test Cycles 0-999999, can be preset
Test Speed ≥10 freq/min
Guard Recovery Detection Time 0.01-9.99s, can be displayed(Recovery time)
Circular Saw Switch Locking Device Lock or release the switch by motor driving
Operation Buttons Stop and Start buttons on the panel for operator easily cut off or turn on the power




Picture for reference:

IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard 0





IEC 60745-2-5 Testing Equipment For Circular Saw Switch And Lower Guard 1
