ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment

ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment

ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment
ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment
ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Calibration certificate(cost additional)
Model Number: HH0813
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood
Delivery Time: 45 days
Payment Terms: T/T
Supply Ability: 5 Sets per month
Contact Now
Detailed Product Description
Test Item: Corrosion Resistance Of The Material Power Supply: 230V,60hz
Relative Humidity: 85% Volume Of Spray: 1~2mL/80cm2·h
Salt Tank Capacity: 15L Spray Pressure: 0.07-0.17MPa(adjustable)
High Light:

ISO3768 Salt Spray Testing Machine

,

Transparent Acrylic Salt Spray Testing Machine

,

Corrosion Resistant Salt Spray Testing Machine

ISO3768 Salt Spray Testing Machine HH0813 PVC&Transparent acrylic material

ISO3768 Salt Spray Testing Machine HH0813 PVC&Transparent Acrylic Material Corrosion Resistant Equipment

Product Introduction:

Salt spray testing machine is a kind of environmental test which mainly uses the artificial simulated salt spray environmental conditions created by salt spray testing equipment to assess the corrosion resistance of products or metal materials. It is one of the "three prevention" test equipment for artificial climate environment (wet heat, salt spray, mold), and is an important test equipment for studying various environmental adaptability and reliability in machinery, national defense industry, light industry electronics, meters and other industries.



Principle and function:

Salt spray testing machine scientific name is "salt spray test box", is the use of salt spray corrosion method to detect the reliability of the tested sample, salt spray refers to the atmosphere by salt containing tiny droplets of the dispersion system, is one of the artificial environment three prevention series, many enterprise products need to simulate the ocean surrounding climate caused by the destruction of products, so the salt spray test box should be shipped.





Technical parameters:



No. Project Parameter
1 operating temperature

(A) Saline test method:

(1) Laboratory :35℃±1℃

(2) Saturated air barrel :47 ° C ±1 ° C



(B) Corrosion resistance test method:

(1) Laboratory: 50℃±1℃

(2) Saturated air barrel :63 ° C ±1 ° C

2 Box humidity more than 85%
3 Test room PVC grey impact resistant plate, thickness 6m/m
4 Constant temperature water tank PVC gray impact resistant plate, thickness 6m/m, and with automatic water level controller, avoid the inconvenience of artificial water
5 Laboratory cover made of transparent acrylic plate, thickness 5m/m
6 Spray volume 1~2ml/80cm²·hr
7 Laboratory temperature control 0~99.9℃,accuracy 0.1℃(double digital display)
8 Time controller adjustable from 0s to 9990hr
9 Integrator 0~9999.9hr can be manually/automatically reset
10 size

Internal size :600*450*400*mm(L*W*H)

External dimensions :1070*600*1180*mm (L*W*H)

Test chamber capacity: 108L

Salt tank capacity :15L



Actual picture of the equipment:

ISO3768 Salt Spray Testing Machine HH0813 PVC Transparent Acrylic Material Corrosion Resistant Equipment 0
