IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter

IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter

  • IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter
  • IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter
  • IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter
IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Third part calibration certificate(cost additional)
Model Number: HJ0629
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: plywood
Delivery Time: 20 working days
Payment Terms: T/T
Supply Ability: 20 set per month
Contact Now
Detailed Product Description
Test Object: Rotary Grills Standard: IEC 60335-2-6
Test: Bearing Capacity Load Thickness: 85.3mm
Diameter: 100mm Mass Of Load: 4.5kg
Name: Testing Rotating Spits Load Material: Stainless Steel
High Light:

IEC 60335-2-6 Electrical Appliance Tester

,

100mm Diameter Electrical Appliance Tester

IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter



3.1.9.104 Rotating spits in ovens or grills are operated with the load on the rotating spit as shown in Figure 103. The appliance is operated taking into account the instructions with regard to
– the heating elements to be operated;
– the setting of the thermal control;
– the position of the door and grill pan.                                     Electrical Appliance Tester
In the absence of such instructions, the control is adjusted to its highest setting and the door is fully open or is placed in the most unfavourable intermediate position in which it may be left.
Any grill pan is placed in its lowest position.



Standard: This device meets the standard of IEC60335-2-9 clause 3.1.9.102 figure 102,Household and similar electrical appliances-Safety-Part 2-9:Particular requirements for grills, toasters and similar portable cooking appliances. This device also meets the standard of IEC60335-2-6 clause 3.1.9.104 figure 103.                         Electrical Appliance Tester

Application: It is used for the bearing capacity testing of rotary grills.

Test sample: Rotary grills.



Technical parameters:

Test object Rotary grills
Reference standard IEC 60335-2-6 figure 103
Test Bearing capacity test
Load diameter 100mm
Load thickness 85mm
Gap of load 20mm
Mass of load 4.5kg               Electrical Appliance Tester
Material stainless steel



Feature:

Full stainless steel material, sturdy and durable



IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter 0

IEC 60335-2-6 Electrical Appliance Tester Load For Testing Rotating Spits 100mm Diameter 1
