IEC 60228 Conductor Resistance Meter High Precision Ultra Low DC Resistance Test Equipment

IEC 60228 Conductor resistance meter

Product Introduction:

CXT2510 Ultra low DC resistance tester is a high precision tester specially designed and developed for ultra low DC resistance test. The measuring range of this instrument is: 0.01uΩ~10MΩ; The display bits are five and a half; Automatic bidirectional current test, pulse test method to avoid the test loop heat affect the test accuracy, the test cable resistivity without a variety of current testing; Test speed up to 30 times/second; The highest test accuracy is 0.02%; Temperature compensation can avoid the influence of ambient temperature on the test work; The CXT2510 series provides multiple interface functions to facilitate data communication and remote control with a PC. The instrument has a professional sorting function, a variety of sorting signal Settings, can be used in automatic sorting system to complete automatic pipeline testing. And can be equipped with RS232 interface and USB interface for remote control and data acquisition and analysis.

Scope of application:

The CXT2510 can be used for various ultra-low DC resistance/resistivity tests such as wire and cable, shunt, metal, and conductor. Can also measure various switch contact resistance; Connector contact resistance; Relay wire package and contact resistance; Transformer, inductor, motor, deflection coil winding resistance (inductive load please choose unidirectional current mode test); Wire resistance; Metal riveting resistance for cars, ships and aircraft; Printed board lines and perforated resistance.

Technical parameters:

CXT150m fixture

CXT2510 Ultra-low DC resistance tester
