| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Calibration certificate(cost additional) |
| Model Number: | LH-40 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood |
| Delivery Time: | 90 days |
| Payment Terms: | T/T |
| Supply Ability: | 2 Sets per month |
| Working Size: | W×D×H 1200×1200×1000mm | Power (kw): | 5kW |
|---|---|---|---|
| Voltage: | 380V | Temperature Range: | RT+10 ℃~300 ℃ |
| Ventilation Time: | 1min~99H Adjustable | Ventilation Rate: | 5~20 Times/h |
| Highlight: | Thermal Ageing Oven IEC Testing Equipment,IEC Testing Equipment 20 Times /H |
||
Thermal Ageing Oven IEC 60811 Testing Equipment Air Changes Rate 5-20 Times Per Hour
Thermal Ageing Oven Introduction:
The aging oven is suitable for testing the aging, elongation, tension resistance and other changes of rubber, plastic and artificial leather. The horizontal forced air circulation system and the air flow adjustment plates on both sides of the interior ensure that the internal temperature of the testing machine is uniform and stable.
Thermal Ageing Oven Standard:
IEC 60811-1-2 Common test methods for insulating and sheathing materials of electric cables Part 1: Methods for general application Section Two — Thermal ageing methods;
IEC 60811-2-1 Common test methods for insulating and sheathing materials of electric and optical cables – Part 2-1: Methods specific to elastomeric compounds – Ozone resistance, hot set and mineral oil immersion tests;
Thermal Ageing Oven Parameter:
| Working size | W×D×H 1200×1200×1000mm(customisable) |
| Power (kw) | 5kw Voltage: 380V |
| Temperature range | RT＋10℃～300℃ |
| Uniformity | ±3℃ |
| Constant temperature fluctuation | ±0.5℃ |
| Ventilation time | Adjustable from 1min to 99h |
| Ventilation rate | 5 ~ 20 times /h |
| Accuracy range |
Setting accuracy: temperature ±0.1℃ indicating accuracy: temperature ±0.1℃ resolution: ±0.1℃ |
| Timing range | 1～9999min |
