| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HT-I06T |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Aluminum Box |
| Delivery Time: | 3 Days |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/ month |
| Product Name: | Test Probe 2 With Force | Warranty: | 1 Year |
|---|---|---|---|
| Usage: | Water Ingress Protection Test | Standard: | IEC61032 Figure 6 Probe 2、IEC60529 Of IP2 |
| Application: | IP2X | Material: | Stainless Steel, Nylon |
| Steel Ball Diameter: | SФ12.5+0.2 | Force: | 30N |
| High Light: | IP2X Ingress Protection Test Equipment,IEC60529 Ingress Protection Test Equipment,30N Test Probe |
||
IEC60529 IP2X Ingress Protection Test Equipment Test Probe 2 With Force of 30N
Standard:IEC61032 figure 6 probe 2,IEC60529 of IP2.
Application:It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 12.5mm or greater.
Test sample:Easily accessible enclosure live parts or mechanical parts.
Feature:Steel ball, rigid test.
Parameters:
| Model | HT-I06 | HT-I06T |
| Name | Test probe 2 steel ball | Test probe 2 with force |
| Steel ball diameter | SФ12.5+0.2 0 | SФ12.5+0.2 0 |
| Force | ---- | With force of 30N |
| Applied standard | IEC61032.1 | IEC60529 |
Picture view:
