| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | calibration certificate(cost additional) |
| Model Number: | CT-4 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Aluminum Box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/ month |
| Product Name: | Touch Current Measuring Circuit | Warranty: | 1 Year |
|---|---|---|---|
| Standard: | IEC60990 | RS: | 1500Ω |
| RB: | 500Ω | CS: | 0.22μF |
| R1: | 10000Ω | C1: | 0.022μF |
| High Light: | Figure 4 Touch Current Measuring Circuit,IEC60990 Touch Current Measuring Circuit |
||
IEC60990 Figure 4 Touch Current Measuring Network Convenient
Products Introduction:
This test network conforms to the measuring network requirements of IEC60990 touch current and the measurement method of protective conductor current, (figure 4-mesuring network touch current weighted (sensory current or reaction current). This network is convenient to use and easy to operate, and the power supply switch is made separately, which can solve the shortcomings of power supply capacity of the previous machine and can test the more powerful products.
Parameter:
| Name | Value |
| RS | 1500Ω |
| RB | 500Ω |
| CS | 0.22μF |
| R1 | 10000Ω |
| C1 | 0.022μF |
Preparation:
Before testing, you need to prepare instruments as follow:
Oscilloscope x1
One or ten times the voltage probe x1
Power supply x1 (the test voltage or frequency that can be adjusted or changed to the required voltage or frequency)
