Stainless Steel Inner Wall IEC Test Equipment 8 - 20 Times / Hour Air Changes

Brand Name:	HongCe
Model Number:	HH0812A
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10 Sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Name:

Natural Convection Oven

Standard:

IEC60065, IEC60884-1 And Etc.

Warranty:

12 Months

Complete Air Changes:

8-20 Times/hour

Inner Wall Material:

Stainless Steel

Outer Chamber Material:

Sprayed Cold-rolled

Max Temperature:

RT+20℃~300℃

Rotary Motor Power:

1/4HP

Inner Size:

1000*1000*1000mm

Temperature Uniformity:

＜2℃

Packaging Details:

Plywood

Highlight:

Inner Wall IEC Test Equipment

Stainless Steel IEC Test Equipment

20 Times / Hour IEC Test Equipment

Product Description

Stainless Steel Inner Wall IEC Test Equipment 8 - 20 Times/Hour Air Changes

IEC Description:

The International Electrotechnical Commission (IEC) is an organization that develops international safety standards for electrical equipment. The IEC standards reduce safety hazards that can occur from unpredictable circumstances when using electrical test equipment such as test instruments and meters.

Safety ventilation system:

1. There is no built-in circulating air system in the inner chamber to ensure temperature uniformity: 1% (calculated based on the highest temperature);

2. Built-in adjustable ventilation outlet , by changing the size of the outlet, the size of the ventilation volume can be appropriately changed, and the adjustment is very convenient

3. Adjustment range of ventilation volume: 8~20 times/hour. Timer: 999.9 hours can be set. (Optional with power-off hold and automatic power-on function) The air flow meter is used to measure the ventilation flow.

IEC Test Equipment Parameters:

1	Inner size	100010001000mm
2	Electric heating power	5.5KW, with two-stage heating selection mode
3	Intelligent PID control, with self-tuning function, instrument accuracy: 0.1 ℃
4	Temperature uniformity	＜2℃
5	Max temperature	RT+20℃~300℃ IEC Test Equipment
6	Sample rotation speed	5~10r.p.m
7	Rotary motor power	1/4HP
8	Stainless steel inner wall and outer chamber are cold-rolled and sprayed
9	Double-layer stainless steel compartment, single-layer stainless steel round turntable IEC Test Equipment
10	Natural ventilation rate	8~20 times/hour
11	With ultra-high temperature protection function, it can effectively protect the safety of equipment

Our Service:

OEM service is available:

We can print customer's Logo and company name on the machine.

Technical service:

Our technical team is much experienced in safety test machine, to manufacture better machine and produce better testing machine. We are able to provide support on machine customize, machine maintenance, engineering design, design optimization, product development.

Quality control:

Our experienced Quality Assurance team is able to control quality whatever during the production, or before the shipment, to guarantee that our customer will only receive quality, but not trouble.

After sale service:

Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.

Picture:

Stainless Steel Inner Wall IEC Test Equipment 8 - 20 Times / Hour Air Changes 0
