IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy

IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy

IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy
IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy
IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Calibrate Certificate (Cost Additional )
Model Number: HH0815
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 10 set /month
Contact Now
Detailed Product Description
Standard: IEC60529, IEC 60335-1, IEC 60598-1 And Etc. Turntable Diameter: Ø600mm (customized)
Turntable Speed: Maximum 1r/min, Adjustable Tiltable Angle: 15°
Test Sample: Home Appliances Or Electrical Parts, Etc. Body Material: Industrial Aluminum Alloy
Application: Waterproof Test Direction Of Rotation: Clockwise Or Anticlockwise
High Light:

Tiltable Rotating Stage Waterproof Test Equipment

,

IEC 60529 Waterproof Test Equipment

,

Waterproof Ingress Protection Test Equipment

IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment, Made of Aluminum Alloy



Product introduction: This turntable comes with an independent control cabinet, which can be used with IPX1~6 waterproof test equipment, to vertify the degrees of protection provided by enclosures. The loading platform can be tilted 15° to meet IPX2 test requirements.
The main material of the turntable is industrial aluminum alloy, the base material is aluminum, and it is easy to move with casters; the control cabinet is also small and light, which is easy to move.                             Ingress Protection Test Equipment
The rotation direction of the turntable can be selected clockwise or anticlockwise at the control cabinet, and the rotation speed is adjustable from 1r/min to 10r/min.



Product Information:

The tiltable rotating stage is designed and manufactured in accordance with the standard requirement of IEC 60884-1, IEC 60335-1, IEC 60598-1 and etc..                                    Ingress Protection Test Equipment



Parameters:

Turntable speed 1r/min-10r/min, adjustable
Diameter Φ600mm
Tiltable angle 15°
Test angle of rotation continuous rotation
Adjustable height of the adjustable telescopic tube 300mm,1200mm-1500mm
Body material Industrial aluminum alloy
Stage network type                                      Ingress Protection Test Equipment
Aluminum base with casters
Reversible control, rotational movement control by the control cabinet


Picture View:



IEC 60529 Tiltable Rotating Stage Work With Waterproof Test Equipment Made Of Aluminum Alloy 0
