Integrated Test Device For Circular Saw Switch And Lower Guard 0-250V 5KW Built - In Load

Integrated Test Device For Circular Saw Switch And Lower Guard 0-250V 5KW Built - In Load

  • Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load
  • Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load
  • Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load
Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: Third party calibration certificate(cost additional)
Model Number: HDD8304
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: Plywood
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 5 set per month
Contact Now
Detailed Product Description
Control: Mitsubishi PLC Station: One, Can Be Customized
Built-in Load: 0~250V/5KW Test Speed: ≥10 Freq/min
Standard: IEC/EN 60745-2-5 Test Sample: Circular Saws
Warranty: 1 Year Application: Circular Saws Performance Test
High Light:

5KW Integrated Test Device

,

Circular Saw Switch Integrated Test Device

,

Mitsubishi PLC IEC Test Equipment

Integrated Test Device For Circular Saw Switch And Lower Guard, 0-250V/5KW Built-in Load



Standard: EN 60745-2-5: 2010 Annex M21.18, Annex M21.18.301, Annex M21.203, Annex M21.301, figure M.301, IEC60745-2-5:2003 Annex BB.20.102, EN 60745-2-5:2010 clause 17.101 and clause 19.102.3.

Application: It is used to test the circular saw switch performance and circular saw lower guard’s durability and recovery time.

Test sample: Circular saws                         IEC Test Equipment

Feature: This equipment is composed of two parts, the mechanical system and electrical control system.

Mechanical system is the table for circular saw. There are a switch and sample socket on the table, operator can push the switch to turn on or off the load power supply to the test sample; different sizes of circular saws can be placed and fixed on the table; on the table, device for locking the switch of the hand-held circular saw in the “on” position; the blade can extend to the bottom of the table through the middle groove; on the table where under the blade, there are a the lower guard putter and two position sensors , which can be drive the lower guard of the circular saw to be opened or closed.                                                                                        IEC Test Equipment

The electrical control system consists of the load power supply, MITSUBISHI PLC, 7 Inch

Touch screen and etc. Can achieve manual operation and automatic operation.

Parameters:

No.: Serial No.: Parameter Remark
1 Input Power 230V/50Hz
2 Control System Mitsubishi PLC, 7-inch touch screen
3 Station One
4 Built-in Load             IEC Test Equipment 0~250V/5KW voltage regulator, equipped with B socket
5 Test Cycles 0-999999, can be preset
6 Test Speed ≥10 freq/min
7 Guard Recovery Detection Time 0.01-9.99s, can be displayed Recovery time
8 Circular Saw Switch Locking Device Lock or release the switch by motor driving
9 Operation Buttons Stop and Start buttons on the panel for operator easily cut off or turn on the power




Picture for reference:

Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load 0

Integrated Test Device For Circular Saw Switch And Lower Guard  0-250V 5KW Built - In Load 1
