IEC62151 Figure 3 Test Probe Length 80mm Diameter 12mm For Information Technology Equipment

Name: IEC62151 Figure 3 Test Probe Length 80mm Diameter 12mm For Information Technology Equipment
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HT-I23
Price: 5,000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HT-I23
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	100 set/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third part calibration certificate(cost additional)

Name:

Test Probe

Model:

HT-I23

Standards:

IEC60065, IEC62151, UL6500

Warranty:

1 Year

Lead Time:

Within Very Short Time

Probe Length:

80mm

Baffle Plate Diameter:

50mm

Material:

Nylon Handle + Stainless Steel Probe

Packaging Details:

Aluminum Box

Highlight:

Figure 3 Test Probe

IEC 62151 Test Probe

Length 80mm Test Probe

Product Description

IEC62151 Figure 3 - Test Probe - Length 80mm Diameter 12mm - For Information Technology Equipment

IEC62151 clause 4.2.2.1 Accessibility
The equipment shall be so constructed that in USER ACCESS AREAS there is adequate protection against contact with bare parts of TNV - 1 , TNV - 2 and
TNV - 3 CIRCUITS except that access is permitted to: Test Finger Probe
– contacts of connectors which cannot be touched by the test probe (figure 3);
– bare conductive parts in the interior of a battery compartment that complies with 4.2.2.2;
– bare conductive parts of TNV - 1 CIRCUITS that are connected to a PROTECTIVE EARTHING terminal;
– bare conductive parts of TNV - 1 CIRCUIT connectors that are separated from unearthed ACCESSIBLE conductive parts of the equipment in accordance with 4.2.1 .2; Test Finger Probe

Compliance is checked by inspection, by measurement and by means of the test finger (IEC 61032, test probe B) applied as specified in the compliance section of the relevant equipment standard), and the test probe, figure 3.

Standard:Conforms to IEC60065: 2014 Annex B, IEC62151 figure 3 and UL6500 figure B.1.

Application:It is used for the bare parts of TNV circuits of information technology equipment to see whether they have sufficient protection.

Test sample:Information technology equipment.

Feature:Nylon handle + stainless steel probe. Test Finger Probe

Parameters:

Model	HT-I23
Probe length	80 Test Finger Probe
End radius	R6
Probe diameter	Φ12
Baffle diameter of the handle	50

IEC62151 Figure 3 Test Probe Length 80mm Diameter 12mm For Information Technology Equipment 0
