Place of Origin: | China |
Brand Name: | HongCe |
Certification: | calibration certificate(cost additional) |
Model Number: | HT-I06 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiatable |
Packaging Details: | Aluminum Box |
Delivery Time: | 3 Days |
Payment Terms: | T/T |
Supply Ability: | 100 set/ month |
Warranty: | 1 Year | Usage: | Water Ingress Protection Test |
---|---|---|---|
Product Name: | Test Probe 2 | Standard: | IEC61032 Figure 6 Probe 2, IEC60529 IP2 |
Material: | Nylon+Stainless Steel | Steel Ball Diameter: | SФ12.5+0.2 |
Color: | White | Function: | Ingress Protection Level Test |
High Light: | IP2 Ingress Protection Test Equipment,IEC 60529 Ingress Protection Test Equipment,Nylon Ingress Protection Test Equipment |
IEC60529 IP2 Ingress Protection Test Equipment Test probe 2 - 12.5mm steel ball
IEC60335-1 Clause 22.1:
If the appliance is marked with the first numeral of the IP system or any of the additional letters of the IP system, the relevant requirements of IEC 60529:1 989 including IEC 60529:1 989/AMD1 :1 999 and IEC 60529:1 989/AMD2:201 3 shall be fulfilled.
Compliance is checked by the relevant tests. Ingress Protection Test Equipment
Standard:IEC61032 figure 6 probe 2,IEC60529 of IP2.
Application:It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 12.5mm or greater. Ingress Protection Test Equipment
Test sample:Easily accessible enclosure live parts or mechanical parts.
Feature:Steel ball, rigid test. Ingress Protection Test Equipment
Parameters:
Model | HT-I06 | HT-I06T |
Name | Test probe 2 steel ball | Test probe 2 steel ball with force |
Steel ball diameter | SФ12.5+0.2 | SФ12.5+0.2 |
Force | ---- | With force of 30N |
Applied standard | IEC61032.1 | IEC60529 |
Ingress Protection Test Equipment
