IEC61032 Figure 6 Probe 2 IEC60529 IP2X Ingress Protection Test Equipment SФ12.5

Brand Name:	HongCe
Model Number:	HT-I06T
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	100 set/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third part calibration certificate(cost additional)

Product Name:

Test Probe 2 With Force

Warranty:

1 Year

Standard:

IEC61032 Figure 6 Probe 2、IEC60529 Of IP2

Steel Ball Diameter:

SФ12.5+0.2

Force:

30N

Color:

Black

OEM:

Yes

Function:

Ingress Protection Level Test

Packaging Details:

Aluminum Box

Highlight:

IP2X Ingress Protection Test Equipment

IEC 60529 Ingress Protection Test Equipment

Figure 6 Ingress Protection Test Equipment

Product Description

IEC61032 figure 6 probe 2 IEC60529 of IP2X Ingress Protection Test Equipment SФ12.5

Standard description(IEC 61032 Clause 5 ):

List of test probes
The comparative list of test probes with their application is given in table 1 . Other IEC publications should refer to a test probe of this standard by means of its code (column 2) and short description (column 4), without reproduction of the relevant figure (column 3).

Table 1 – List of test probes

Probe and application

Probe

code

Figure

No.

Short description

Forces to

be applied

Access probes of IEC 60529

(IP code)

to verify protection of persons against

access to hazardous live parts or

hazardous mechanical parts

– Sphere: Ф 50 with handle

– Jointed test finger

– Rod: Ф 2,5 – length 1 00

– Wire: Ф 1 ,0 – length 1 00

1 0

Object probes of IEC 60529

(IP code)

to verify protection of equipment

against ingress of solid foreign

objects

– Sphere: Ф 50

– Sphere: Ф 1 2,5

……

Standard:IEC61032 figure 6 probe 2,IEC60529 of IP2.

Application:It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 12.5mm or greater.

Test sample:Easily accessible enclosure live parts or mechanical parts.

Feature:Steel ball, rigid test.

Parameters:

Model	HT-I06	HT-I06T
Name	Test probe 2 steel ball	Test probe 2 with force
Steel ball diameter	SФ12.5+0.2 0	SФ12.5+0.2 0
Force	----	With force of 30N
Applied standard	IEC61032.1	IEC60529

Picture view:

IEC61032 Figure 6 Probe 2 IEC60529 IP2X Ingress Protection Test Equipment SФ12.5 0

IEC61032 Figure 6 Probe 2 IEC60529 IP2X Ingress Protection Test Equipment SФ12.5 1

IEC61032 Figure 6 Probe 2 IEC60529 IP2X Ingress Protection Test Equipment SФ12.5 2
