products details

Home Products

Temperature sensing controls Testing Equipment IEC 60730-1 House Hold Controls

Brand Name:	HongCe
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:	15 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)

Test:

Life Test, On Off Test

Test Object:

Temperature Sensing Controls

Stations:

3 Stations

Control:

Touch Screen

Power Supply:

220VAC 50Hz

Electric Load:

Available

Packaging Details:

Plywood

Highlight:

electrical appliance tester

portable appliance tester

Product Description

Temperature sensing controls Testing Equipment IEC 60730-1 House Hold Controls

Product information:

This device conforms to the standard requirement of the IEC 60760-1, IEC 60730-2-9, GB 14536.1, GB 14536.10 and related standard test requirements to temperature sensing controls for house hold and similars.

It is an highly automatic intelligent equipment, with multiple function, can be use to perform on off test and life test, with the function of heating, blow cooling, electric loading, timing, auto stop and alarm function. Equiped with PLC and touchscreen, digital display meters.

Operation is easy and convienent, all parameters can be set on touchscreen, set parameters and install test sample, press start, the device will complete the test automatically.

Technical parameters:

Power supply: 220VAC / 50Hz.
Test: life test, on off test
Test stations: 3 stations
Electric load: available
Load voltage: Max. 300V
Load current: Max. 21.5A
Controller: Touchscreen + PLC + digital display meters
Test object: temperature sensing controls
Standard: GB 14536.1, GB 14536.10, IEC 60730-1, IEC 60730-2-9
Function: Heating, blow cooling, auto stop, alarm
Alarm: when test finished or test sample in fault
Protection: Emergency stop

Operation procedure:

Install samples to be test
Set Test Times in Test Interface
Select Automatic Reset (default is auto reset)
Press LOAD ON / OFF button, select load current
Heating delay setting: to set this time, please consider the heating time from ambient to tripping limit temperature. Set a long time can check the on off alarm function.
Blow reset delay setting: this is the blow cooling time from tripping to contacts reset. Set a long time can check the on off alarm function.
Go Main interface, press ZERO clear all data.
Then adjust the intake compressor air pressure to approximate 6 to 7 kg.
Press START on Main interface. Test equipment will start and complete the test.
