Diameter 12.5mm Test Probe 2 With Force Of 30N IP Code - IP2X

Brand Name:	HongCe
Model Number:	HT-I06T
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	100 set/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third part calibration certificate(cost additional)

Test Sample:

Live Parts Or Mechanical Parts

Color:

Black

Force:

10N, 20N, 30N

Test Type:

Rigid Test

Product Name:

Test Probe 2 With Force

Standard:

IEC61032 Figure 6 Probe 2、IEC60529 Of IP2

Application:

IP2X

Steel Ball Diameter:

SФ12.5+0.2

Packaging Details:

Aluminum Box

Highlight:

Diameter 12.5mm Test Probe

IP2X Test Probe

30N IP Code Test Probe

Product Description

Diameter 12.5mm Test Probe 2 With Force of 30N, IP Code - IP2X

The product is made of nylon and stainless steel. The nylon part of the handle is black, and the probe part is a 12.5mm stainless steel ball. The scale part is silk screen printing, which is clear and not easy to fade. It can achieve force of 10N, 20N and 30N. The end is equipped with wiring terminals for anti electric shock test.

Ingress Protection Test Equipment

Standard:IEC61032 figure 6 probe 2,IEC60529 of IP2.

Application:It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 12.5mm or greater.

Test sample:Easily accessible enclosure live parts or mechanical parts.

Feature:Steel ball, rigid test. Ingress Protection Test Equipment

Parameters:

Model	HT-I06T
Name	Test probe 2 steel ball with force
Steel ball diameter	SФ12.5+0.2
Force	With force of 30N
Applied standard	IEC60529

Picture for reference:
