Automatic Helium Leak Testing Machine Built for Flexible Custom Fixture Design

Name: Automatic Helium Leak Testing Machine Built for Flexible Custom Fixture Design
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HC-HLT-F4
Price: 5000.00 USD
Availability: InStock

Brand Name:	HongCe
Model Number:	HC-HLT-F4
MOQ:	1 set
Price:	Negotiation
Payment Terms:	L/C,T/T
Supply Ability:	1 set per 3 months

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Control System:

PLC With HMI And Recipe Storage

Positioning Repeatability:

+/- 0.05 Mm

Fixture Changeover Time:

Under 5 Minutes

Test Cycle:

10 S/pc

Compatible Workpieces:

Compressor Shells, Heat Exchangers, Valves, Receivers

Fixture Type:

Custom Quick-change Fixture

Detection Method:

Helium Mass Spectrometry, Vacuum Mode

Packaging Details:

Plywood

Highlight:

Custom Fixture Design

Flexible Workpiece Handling

Rapid Fixture Changeover

Product Description

Automatic Helium Leak Testing Machine Built for Flexible Custom Fixture Design

Automatic Helium Leak Testing Machine with Custom Fixture Design

A good leak test is only as good as the fixture that holds the part. If the fixture does not seat the workpiece the same way every time, the result is not repeatable, and the operator spends more time adjusting than testing. HongCe designs the HC-HLT-F4 around the fixture, because that is where most field problems begin.

Fixtures Designed Around Your Part

We start from your drawing. The sealing faces, locating points and clamping method are designed so the part sits in the same position on every cycle, and so that loading and unloading are quick and obvious for the operator.

One Station, Several Models

Manufacturers rarely test a single model. The HC-HLT-F4 uses quick-change fixtures and stored recipes, so switching from one compressor model to another is a matter of swapping the fixture and calling up the recipe. Changeover is typically completed in under five minutes.

Technical Specifications

Item	Specification
Fixture type	Custom quick-change fixture
Fixture changeover time	Under 5 minutes
Compatible workpieces	Compressor shells, heat exchangers, valves, receivers
Positioning repeatability	+/- 0.05 mm
Test cycle	10 s/pc
Control system	PLC with HMI and recipe storage

Typical Applications

The machine is used where product lines carry several models with different shapes and sealing points, and where changeover time directly affects output.

Engineering and Service Support

HongCe provides fixture design, sample testing and drawing approval before manufacture. We keep your fixture drawings on file so replacement fixtures and future models can be produced quickly, and our engineers support fixture trials on site or by video call.

Frequently Asked Questions

Can you design a fixture for a part we have not yet produced?

Yes. Send the drawing and we will propose a fixture and test method for review.

Do we have to order a new machine for every new model?

No. New fixtures and recipes are usually enough, provided the part fits within the machine envelope.

Request a Configuration

Share your parts and the models you expect to run, and we will design a fixture plan that keeps changeover short and results repeatable.
