Pump Testing Equipment AC 200-3000V High Precision Pump Motor Testing System for Single Three Phase Motors

The water pump motor test system, designed specifically for the water pump industry, is suitable for testing single- and three-phase water pump motors and their stators, covering a wide range of pump types, including canned motors, self-priming pumps, centrifugal pumps, deep-well pumps, and submersible pumps. The system integrates multiple test functions, including AC withstand voltage, insulation resistance, direction testing, no-load testing, and low-voltage starting. It quickly completes pre-set tests in a single setup, providing an efficient and comprehensive solution for water pump motor performance evaluation and quality control, and is widely used in various water pump manufacturing scenarios.

Product Features

• Comprehensive Functionality: Integrates multiple core test functions, including AC withstand voltage, insulation resistance, direction of rotation, no-load, and low-voltage starting, meeting the multi-dimensional testing needs of water pump motors.
• Precise Testing: Highly accurate parameters for each test item. For example, the AC withstand voltage output voltage setting range is AC 200-3000V, with an accuracy of ±(3% × set value + 5 digits), accurately capturing motor performance details.
• Efficient and Convenient: Complete multiple test items in a single clamping operation, significantly reducing testing time and improving production testing efficiency.
• Wide Adaptability: Suitable for testing single-phase and three-phase water pump motors and stators, covering a wide range of pump types, meeting the testing needs of various water pump manufacturers.

International Reference Standards

• The IEC 60034 series of standards covers the ratings, performance, and test methods of rotating electrical machines, providing fundamental specifications for motor design, production, and testing. This system's parameter settings and test methods for AC withstand voltage and insulation resistance tests refer to the relevant clauses of this series of standards.
• ISO 9906: This standard specifies hydraulic performance testing for centrifugal, mixed-flow, and axial-flow pumps. This system's load/no-load testing, which simulates actual pump operating conditions, references this standard's requirements for pump performance testing, ensuring that test results accurately reflect the performance of the pump motor under actual operating conditions.

Product Applications
This product is primarily used by water pump manufacturers to conduct comprehensive pre-shipment inspections and assessments of pump motors and stators. This ensures that the pump motors meet expected quality standards and performance indicators upon shipment, ensuring overall pump operational stability and reliability. It is widely used in various water pump manufacturing scenarios.

Test Objects
Applicable to single-phase and three-phase water pump motors and their stators, covering motors for various pump types, including shielded pumps, self-priming pumps, centrifugal pumps, deep-well pumps, submersible pumps, sewage pumps, pipeline pumps, and refrigeration pumps.

Testable Items
AC withstand voltage, insulation resistance, turn-to-turn withstand voltage, DC resistance, direction of rotation test, no-load test, and low-voltage starting.

Technical Parameters
