| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HDX1301 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | plywood |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20 set per month |
| Name: | Universal Conductor Resistance Fixture | Standard: | IEC60245 |
|---|---|---|---|
| Warranty: | 1 Year | Sample Length: | 100~1000mm |
| Dimensions: | 1530 × 210 × 150mm | Adapting Electrical Bridge: | QJ84 Double Bridge Etc., Optional |
| Application: | Cable Testing Equipment | Material Of Clamp: | Copper |
IEC60245 Cable Tester with Universal Conductor Resistance, Providing Reliable Testing.
Standards Compliance
Complies with IEC60245-1 (Rubber insulated cables - General requirements for rated voltages up to and including 450/750 V) and IEC60245-2 (Test methods for rubber insulated cables with rated voltages up to and including 450/750 V).
Application Scope
Suitable for DC resistance measurement of various power cables and electrical equipment.
Applicable to wire and cable equipment as specified in "Test methods for electrical properties of electric cables and wires".
Can be used for DC resistance measurement of other conductor materials.
Test Sample Specifications
Can test 1mm² to 630mm² single or multi-strand conductors and cores of power cables.
Equipment Features
Adopts a fast clamp and withdraw structure with positive and negative threaded rods.
Has separated voltage and current clamps to enhance sample contact.
Equipped with an aluminum alloy base plate and copper clamps.
Parameters:
| The distance of clamping head between two voltage | 100~1000mm |
| Dimensions | 1530 × 210 × 150mm |
| Adapting electrical bridge | QJ84 double bridge, Optional. |
Picture view:
Company Advantages
Product Development: The company has its own R & D and design team, providing customers with technological and innovative products and unique designs based on customer ideas.
Technical Support: All workers are experienced and skilled.
After-sale Service: The working and sales teams ensure fast and efficient global after-sale service.
Company Profile
Establishment and Location: Established in 2003 in Guangdong, China, it is a pioneering enterprise in the inspection equipment industry.
Production Process and Quality Control: Incorporates advanced technologies and equipment, with a strict quality control system covering all production stages.
Team and Management: Comprises skilled high-tech managers using modern management practices, computer-aided design, and control to ensure products meet international standards.
Business Model: Integrates R & D design, production, and sales.
Product Range: Specializes in manufacturing a wide variety of testing equipment, including flammability, battery, home appliance, helium leak, cable, IP, general, and non-standard testing equipment. The products are widely recognized and popular both domestically and internationally, with strong partnerships with many renowned companies.
