| Place of Origin: | China |
| Brand Name: | HongCe |
| Certification: | Third part calibration certificate(cost additional) |
| Model Number: | HDX1314 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | plywood |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20 set per month |
| Standard: | UL817 | Stations: | 6 |
|---|---|---|---|
| Load Current: | 0~40A , Arbitrary Adjustable | Load Voltage: | 4~12V |
| Warranty: | 1 Year | Ambient Temperature: | 0~40℃ |
| Ambient Humidity: | Less Than 85%Rh | Test Time: | 0.1~999.9S |
| High Light: | 9999 Test Times Cable Testing Equipment,Abrupt Removals Cable Testing Equipment,Power Cord Cable Testing Equipment |
||
Power Cord Abrupt Removals Cable Testing Equipment Capable of 1~9999 Test Times
Description of Cable Testing Equipment:
Purpose: Used for plug power cord sudden tensile strength test, torsion test, load test and ground wire current test
Sample range: plug power cord
Structure and function: The test adopts automatic working mode. The testing machine stops when the set times or set time are reached.
Technical parameters:
| Power supply | AC 220V 50Hz |
| Load current | 0~40A , Arbitrary adjustable |
| Load voltage | 4~12V |
| Working station | 6 stations |
| Test times | 1~9999 times, can be preset |
| Test time | 0.1~999.9S |
| Load weight | 2.5 pound(lb) , 3 pound(lb) , 15 pound(lb) 6 pcs per each |
| Ambient temperature | 0~40℃ |
| Ambient humidity | less than 85%Rh |
| Reference standard |
UL817 clause 99.1-99.2 Abrupt Pull Test, clause 100.1-100.3 Jacket retention test |
Testing Equipment detail drawing:
Our advantage service:
We possess a professional R&D and design team that leverages their proficient skills and innovative thinking to provide customers with uniquely crafted product solutions. If you have any novel ideas or unique needs for a product, please feel free to share them with us, and we will carefully craft a one-of-a-kind product design based on your creativity and expectations, meeting all your aspirations.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our professional working team and outstanding sales team are committed to providing our clients with products worldwide and guaranteeing fast and efficient after-sales services to meet various needs.
About Us:
Guangzhou Hongce Equipment Co., Ltd is a leading company in inspection equipment industry, established in 2003 and located in Guangdong, China. Our company introduced advanced equipment, combined with the most advanced technology production processes, strict quality control system to control the entire process of production. The company combined with a number of high-tech management personnel and advanced equipment, and together with the modern management, computer design and control, our products has reached the international advanced level. The company integrates R&D design, production, and sales into one cohesive unit, specializing in the manufacture of a diverse range of testing equipment, including flammability testing equipment, battery testing equipment, home appliance testing equipment, helium leak testing equipment, cable testing equipment, IP testing equipment, general testing equipment, as well as other non-standard testing equipment.Our products enhance good selling at home and abroad, and have established supply relationships with a number of well-known companies.
