0.01uΩ - 10MΩ Cable Testing Equipment Conductor Resistance Meter Basic Accuracy 0.02%

0.01uΩ - 10MΩ Cable Testing Equipment Conductor Resistance Meter Basic Accuracy 0.02%

Brand Name:	HongCe
Model Number:	CXT2510
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional )

Name:

Conductor Resistance Meter

Measuring Range:

0.01uΩ～10MΩ

Warranty:

1 Year

Resistance Accuracy:

Basic Accuracy 0.02%

Maximum Test Current:

10A

Test Terminal Configuration:

Four Terminals

Save Measurement Parameters:

10 Groups

Measurement Parameters:

Basic Accuracy: 0.1 ℃

Packaging Details:

carton box

Highlight:

Conductor Resistance Cable Testing Equipment

Accuracy 0.02% Cable Testing Equipment

Product Description

0.01uΩ - 10MΩ Cable Testing Equipment Conductor Resistance Meter Basic Accuracy 0.02%

Product description:

This resistance tester is a high-precision tester specially designed and developed for ultra-low DC resistance test. The measuring range of the instrument is: 0.01u Ω ~ 10m Ω; The display digit is five and a half digits; Automatic bidirectional current test, pulse test method avoids the heat generated by the test circuit and affects the test accuracy. When testing cable resistivity, multiple current tests are not required; The test speed can reach 30 times per second; The test accuracy can reach 0.02%; Temperature compensation can avoid the influence of ambient temperature on the test work; Multiple interface functions are provided to facilitate data communication and remote control with PC.

It can be applied to various ultra-low DC resistance / resistivity tests of wires and cables, shunts, metals, conductors, etc., and can also measure various switching resistance; Relay wire packaging and contact resistance; Contactor resistance; Wire resistance; Transformer, inductance, motor, damper wind resistance (inductive load, please use unidirectional current mode test); Resistance of automobile metal to ships and aircraft, etc.

Parameter:

Model	CXT2510
Display
Display	24-bit color, true color IPS LCD screen with 800*480 resolution
Reading digits	5½bit
Resistance measurement
Measuring range	0.01uΩ～10MΩ
Resistance accuracy	Basic accuracy 0.02%
Maximum test current	10A
Measurement function
Resistance measurement time	Fast speed: 7ms Medium speed: 42ms Slow speed/Fine measurement: 82ms (The above display is turned on, plus 15ms)
Thermoelectric potential elimination	√
Test terminal configuration	Four terminals
Save measurement parameters	10 groups
Temperature measurement
Measurement parameters	Basic accuracy: 0.1 ℃
Display range	-10℃ ~ 99.9℃
Humidity measurement
Measurement parameters	Basic accuracy: ±1.5%RH
Display range	0~100%RH
Comparators
Signal output	HI / PASS / LO / FAIL
Swift	Pass/Fail/Close
Limit setting method	3 gears; absolute upper/lower limit; percentage upper/lower limit + nominal value
Other
Interface	USB HOST / USB DEVICE /RS232 / HANDLER / RS485
Size and weight	LWH: 400350130mm, 10KG

Feature:

The highest resistance accuracy: 0.02%; the smallest resistance resolution: 0.01uΩ
Maximum test range: 0.01uΩ～10MΩ
Temperature compensation function (TC); basic temperature accuracy: 0.1 ℃
Zero base design, weak resistance test does not need to be cleared
3 gear comparison function: qualified/over upper limit/over lower limit
Multiple trigger methods: internal, external, contact and manual trigger.
Maximum test speed: about 100 times/sec
HANDLER/USB/RS232C/RS485 Interface for remote control
Simultaneous measurement of environmental humidity
U disk records test data, and can remotely upgrade the instrument software

0.01uΩ - 10MΩ Cable Testing Equipment Conductor Resistance Meter Basic Accuracy 0.02% 0
