IEC60335-2-24 Electrical Appliance Tester Refrigerator Door Endurance Tester Angle of Door - 90°

IEC60335-2-24 Electrical Appliance Tester Refrigerator Door Endurance Tester Angle of Door - 90°

Brand Name:	HongCe
Model Number:	HJ0636C
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	10 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Product Name:

Refrigerator Door Endurance Tester

Standard:

IEC 60335-2-24, IEC 62552-1

Application:

Refrigerator Door Test

Test Station:

Revolving Door, Drawer

Load Voltage:

0-250V, Adjustable

Revolving Open Close Door Angle:

0-90°，can Be Preset

Drawer Door Opening Distance:

0-100mm，can Be Preset

Required Air Source:

0.5-0.7MPa Compressed Air

Packaging Details:

plywood

Highlight:

IEC60335-2-24 Electrical Appliance Tester

Door Endurance Electrical Appliance Tester

Refrigerator Door Endurance Tester

Product Description

IEC60335-2-24 Electrical Appliance Tester Refrigerator Door Endurance Tester, Angle of Door - 90°

Standard:
IEC60335-2-24:2012 clause 22.112, IEC60552-1:2007 clause 11.2 and 11.3 Electrical Appliance Tester

Technical parameters:

Specimen Range, Use, Principle, Structure And Use Environment
Samples And Limitations	Refrigerating Appliances (Refrigerator)
Test Purposes	It is used for endurance life testing of interlocks or guides for refrigerator doors or drawers to verify the reliability of interlocks; also used to assist other tests for repeated door opening and closing operations, such as defrosting test and refrigerant leak test
Test Principle	The motor drives the manipulator, driving the door or cover sucked by the Vacuum sucker to reciprocate at a certain speed, to verify the reliability of interlocking device.
Structure	The equipment is divided into an electrical control cabinet (including load voltage regulator), a frame and a robot arm. Size:1500×1300×2200(mm)W×D×H Weight :140kg
Operation Environment	Power supply :AC220V±10%/50-60Hz,power :6KW Air source :0.5-0.7MPa Compressed air Place Of Use :Atmospheric pressure 80 ~ 106kpa；Ambient temperature 5～40°C；relative humidity(20～80)%RH；No violent shaking, vibration, no electromagnetic interference, no dust, no explosive and corrosive gas, good heat dissipation
Performance
Test Station	Revolving Door Action Position Drawer action station Electrical Appliance Tester
Electrical Control Method	PLC intelligent integrated control, 7-inch human-machine touch interface operation
Drive Mode	Servo motor drive
Sample Clamping Method	Vacuum sucker
Open/Close Door Speed	Revolving Door Action:0-360°/s(1.5m/s),can be preset Drawer action:0-100mm/s, can be preset
Revolving Open Close Door Angle	0-90°,can be preset
Drawer Door Opening Distance	0-100mm,can be preset
Test Times	0-999999 times ,can be preset
Load Voltage	0-250V,adjustable Electrical Appliance Tester
Test Item And Crafting Process	1. Refrigerator door interlock device endurance test Process:Vacuum sucker automatic suck the door---- Open the door to a preset angle at a preset speed(45°)---- close the door at preset speed---- Repeatedly open and close the door until reaches the test times 2. Refrigerator drawer door endurance test Process:Vacuum sucker automatic suck the door---- Open the drawer to the preset distance at a preset speed(15-25mm)----Close drawers at preset speed----Repeatedly open and close the drawer until reaches the test times
Safety Protection Device
Power	Leakage protection, overload and short circuit protection
Motor	Overload, short circuit protection

Picture view:

IEC60335-2-24 Electrical Appliance Tester Refrigerator Door Endurance Tester Angle of Door - 90° 0
