IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc

IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc

  • IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc
  • IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc
  • IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc
IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)
Model Number: HT-I32
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiatable
Packaging Details: Aluminum Box
Delivery Time: 3 Days
Payment Terms: T/T
Supply Ability: 100 set/ month
Contact Now
Detailed Product Description
Name: Surface Temperature Probe Warranty: 1 Year
Standard: IEC60335-2-11, IEC60335-2-6 Polycarbonate Tube: Inside Diameter:Φ3
Measuring Surface: Φ5*0.5mm Force: 4±1 N
Thermocouple: Φ0.3K Type Test Sample: Cooking Ranges And Ovens
High Light:

IEC60335-2-6 Test Finger Probe

,

Tinned Copper Disc Test Finger Probe

IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc



IEC60335-2-6

During the test, the temperature rise of surfaces shall not exceed the values specified in Table 103.

IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc 0

If the oven door is protected by a guard, the temperature rise limits in Table 103 specified for the front surface of oven doors apply to the guard. However, if the guard is a detachable guard the temperature rise limits in Table 103 specified for other surfaces apply to parts of
the oven door protected by the guard.               Test Finger Probe
For ovens intended to be used on a working surface the temperature rise limits in the relevant Table 103 specified for parts situated more than 850 mm above the floor apply.

If the oven can be used for grilling and the instructions state that for grilling the door should be closed, the test is repeated but with the oven operating in the grilling mode with the controls set according to the instructions. The grill is operated for 30 min in accordance with 11.7.103. However, if the oven has a rotating spit, the duration of the test is 60 min, with the controls set to give the most unfavourable conditions specified in the instructions. The measurements are only carried out on surfaces for which temperature rises for the front surface of oven doors apply.                     Test Finger Probe



Standard:IEC60335-2-11 figure 101 and IEC60335-2-6-2002 figure 104.

Application:It is mainly used to measure the temperature rise on the front surface of the easily accessible parts of drum-type dryer, upright electric cooker, cooking bench and oven.                                                  Test Finger Probe

Test sample:Drum-type dryer, upright electric cooker, cooking bench and oven.

Feature:Hand held exterior temperature measurement.



Parameters:

Model HT-I32
Measuring surface Φ5*0.5mm Tinned copper disc
Polycarbonate tube Inside diameter:Φ3; outside diameter:Φ5
Thermocouple Φ0.3K type
Handle arrangement permitting a contact force 4±1 N                   Test Finger Probe


IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc 1

IEC60335-2-6 Test Finger Probe Surface Temperature Probe Φ5*0.5mm Tinned Copper Disc 2
