IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen

IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen

  • IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen
  • IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen
  • IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen
IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen
Product Details:
Place of Origin: China
Brand Name: HongCe
Certification: calibration certificate (cost additional)
Model Number: HJ0637
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 15 set/ month
Contact Now
Detailed Product Description
Name: Microwave Oven Door Endurance Tester Test Sample: Microwave Oven
Working Station: One Driver: Servo Driver
Touch Screen: 7 Inch Open Angle: 0-180°preset
Test Times: 0-999999 Open/Close Time: 0-9999S Preset
High Light:

Microwave Oven Door Endurance Tester

,

2kw Microwave Oven Door Endurance Tester

,

Touch Screen Oven Door Endurance Tester

IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen



This clause of Part 1 is replaced by the following.
The door system, including hinges, microwave seals and other associated parts, shall be constructed to withstand wear that may be expected in normal use.
Compliance is checked by the following test.
The door system is subjected to 50 000 cycles of operation with the appliance supplied at rated voltage and containing an appropriate microwave-absorbing load. It is then subjected to 50 000 cycles of operation without microwave generation.
The door is opened and closed as in normal use. It is opened from the closed position to a position approximately 10° before fully open. The rate of operation is 6 cycles per minute. With the agreement of the manufacturer, the rate of operation without microwave generation can be increased to 12 cycles per minute.
After the test, the microwave leakage shall not exceed the limit specified in Clause 32 and the door system shall still function.
NOTE 101 Controls can be rendered inoperative in order to carry out the test.
NOTE 102 Components, the deterioration of which does not impair compliance with this standard, can be replaced in order to complete the test.
NOTE 103 Bricks or additional water of maximum 500 g can be added if necessary to avoid stopping of the test due to overheating.



Standard: IEC 60335-2-25 household and similar electrical appliances – safety: part 2-25:particular requirements for microwave ovens, including combination microwave ovens, clause 18.

Application: The device is used for mechanical endurance test to microwave oven door system includes a hinge structure, microwave seals and other related components.

Test sample: Microwave oven, oven

Feature: The equipment adopts PLC and stepper motor control, with all stainless steel mechanical hand, vacuum suction structure, standard TFT true color LCD touch screen, can preset test angle and speed, simulated a human hand to open and close the door of microwave ovens and similar equipment, achieve intelligent control. The machine frame is made of high grade aluminum alloy profile, and the mechanical arm is installed on the support of the frame, can satisfy left open and upper open door endurance test of different size. The power supply socket has the function of detecting, which can judge whether the test sample is electrified; during load test, if the test sample is not electrified during the test, the equipment will be automatically shut down. This feature can be enabled on the demands.



Parameters:

Control PLC
Display True color liquid crystal display (7 Inch Touch screen)
Frame structure High grade aluminium profile
Power supply AC 220V 50HZ
Test times 0-999999 preset, automatic stop when test time finished
Open/Close time 0-9999S preset
Open/Close rate Adjustable
Open angle 0-180°preset
Station One station(left open or top open)
Door unlock Eccentric wheel mechanism automatic unlock the door lock
Dimension 1000*1000*800mm
Load Provided with a 10A power socket, can be used for samples below 2000W

IEC60335-2-25 Microwave Oven Door Endurance Tester 2kw With Touch Screen 0
