IEC60335-2-15 Dripping Test Apparatus 30ml For Cordless Kettle 200mm Distance

Brand Name:	HongCe
Model Number:	HJ0634
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	30 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration certificate(cost additional)

Name:

30ml Dripping Test Apparatus

Warranty:

1 Year

Test Sample:

Cordless Kettle

Material:

Corrosion-resistant Materials

Standard:

IEC60335-2-15, IEC60320-1

Volume:

30ml

Funnel Diameter:

Φ8mm,length 30mm

Distance:

200mm

Packaging Details:

Carton box

Highlight:

IEC60335-2-15 Dripping Test Apparatus

30ml Dripping Test Apparatus

Cordless Kettle Dripping Test Apparatus

Product Description

IEC60335-2-15 Dripping Test Apparatus 30ml For Cordless Kettle, 200mm Distance

Standard: IEC60335-2-15 clause 15.2 figure 101 of Household and similar electrical appliances – Safety: Part 2-15: Particular requirements for appliances for heating liquids, IEC60320-1 clause 14.2 figure B.1. Electrical Appliance Tester

Application: The device is used to check structure of the weight-engaging connectors (cordless kettle) with liquid spill protection measures when installed in a representative voltage base in accordance with the manufacturer's installation instructions, whether the connector is affected by liquids.

Test sample: Cordless kettle Electrical Appliance Tester

Feature: 30 mL of a solution containing 1% of sodium chloride is poured into the connector through a funnel of the apparatus within 2S, and then subjected to an electric strength test.

Parameters:

Parameters / Model	HJ0634
Funnel diameter	Φ8mm,length 30mm
Distance	The bottom of the funnel is 200mm away from the sample, adjustable
Material	Corrosion-resistant materials

Picture for reference: Electrical Appliance Tester

IEC60335-2-15 Dripping Test Apparatus 30ml For Cordless Kettle 200mm Distance 0

IEC60335-2-15 Dripping Test Apparatus 30ml For Cordless Kettle 200mm Distance 1
